$get_battery_cap_db
Parameter type is PD_GetBatteryCapDataBlock. Refer to PD_GetBatteryCapMsg for available fields of this
type.
Result
None
Examples
$get_battery_cap_db = PD_GetBatteryCapDataBlock
Call PD_SetGetBatteryCapDataBlock( $get_battery_cap_db )
5.1.55 PD_SetGetBatteryCapSetting
Applies settings to GetBatteryCap related commands in PD Exerciser. It must be called
before PD_WaitForGetBatteryCap or PD_DelayAutoResponse to take effect.
Format
Call PD_SetGetBatteryCapSetting( PD_GetBatteryCap_Settings $settings )
Parameters
$settings
Parameter type is PD_GetBatteryCap_Settings. Available fields for this type are:
Field Names
Description
WaitTimeout
Wait TimeOut(micro second) to receive GetBatteryCap
message.
Default: PD_DEFAULT_TIMEOUT_INFINIT
ResponseType
Indicates response upon receiving the GetBatteryCap
message.
Possible values:
PD_RESPONSE_NOT_SUPPORTED,
PD_RESPONSE_UNSPECIFIED(default)
Result
None
Examples
$getbattcap_setting = PD_GetBatteryCap_Settings
{
ResponseType = PD_RESPONSE_NOT_SUPPORTED
}
Call PD_SetGetBatteryCapSetting( $getbattcap_setting )
5.1.56 PD_WaitForGetBatteryCap
Waits for user-defined time-out to receive Get_Battery_Cap message. It will respond to
incoming messages as part of GetBatteryCap AMS.
Format
Call PD_WaitForGetBatteryCap()
Parameters
None
