Data Sheet

ca./approx.
AS
AS
19677 WA19.02.2008a
b 14.06.201122919
06.05.2013c 24828
Gewicht/
weight
[g]
HI
06.12.2007
Maße/ dimensions: mm
33Blatt/ sheet von/ of
Original : DIN A4
Änd./
rev.
Index
Datum/
date
Name/
name
Änderungs-Nr. /
revision code
Benennung/
title
Maßstab/
scale
Datum/
date
Name/
name
gez./
drawn
gepr./
appr.
Ersatz für/
replaces
Zeichnungsnr./
drawing no.
Unterl./
doc. type
STX RJ45 Kupplung Cat.6
1:1
WA 10.09.2007
J80029A0010
(1:1)
D
Alle Rechte vorbehalten / all rights reserved © Telegärtner K.Gärtner GmbH D-71144 Steinenbronn Lerchenstrasse 35 Germany Phone: [phone] Fax: [phone] www.telegaertner.com
untol. Maße/
dim. without
tolerances
according to
STX RJ45 coupler Cat.6
Übertragungstechnische
Eigenschaften
Transmission Performance
10 Gigabit Ethernet gemäß IEEE 802.3an
geeignet für 10 Gigabit Ethernet
Adequate for 10 Gigabit Ethernet
10 Gigabit Ethernet acc. to IEEE 802.3an
Normen Standards
Anwendungsneutrale
Kommunikationskabelanlagen
ANSI/TIA/EIA-568-C.2
ISO/IEC 11801
EN50173-1
ISO/IEC 24702
DIN EN 61918
Generic cabling systems
Anwendungsspezifische
Kommunikationskabelanlagen
Profinet Installation Guideline Custom-designed cabling systems
UL Norm für
Kommunikationszubehör
UL 1863
UL standard for communication-circuit
accessories
IP-Schutzarten IEC 60529
Degrees of protection provided by
enclosures (IP code)
Zulassung Approval
UL-gelistet applied for approval UL listed
3P Third Party Testing
Typmusterprüfung
Attestation of Conformity No.107526
ISO/IEC, EN & TIA/EIA Screened
Class E / Category 6
Three Connector Permanent Link
3P Third Party Testing
Type Approval
3P Third Party Testing
Typmusterprüfung
Attestation of Conformity No.107525
ISO/IEC, EN & TIA/EIA Screened
Class E / Category 6
Four Connector Channel
3P Third Party Testing
Type Approval
GHMT
Typmusterprüfung
Certificate No. P1756c-07
3-Connector Permanent Link (70m)
bis /up to 250MHz (Cat.6)
GHMT
Type Approval
GHMT
Typmusterprüfung
Certificate No. P1755c-07
4-Connector Channel (90m)
bis / up to 500MHz (Cat.6A)
GHMT
Type Approval
