Gm882 USER’S GUIDE INTRODUCTION Thank you and congratulations for having bought a Telit mobile phone. The Gm882 is a GSM dual band, that works fully automatically on the double frequency band (GSM 900-1800 MHz, on condition that the network operator offers this service) and guarantees an excellent quality of conversation and a wider range of the coverage of the radio signal; you can use it in all countries of the European Union and in any country that has implemented GSM networks.
USEFUL NUMBERS & CODES Would you like to have more information on Telit products, or on your Gm882? Have you got any suggestions for improvement? Visit our site www.telit.net, or send us an e-mail to info@telit.net. There are some safety numbers and codes for the use of your phone that you should remember.
SAR CERTIFICATION Like all radio transmitters, the Gm882 emits electromagnetic waves. For user’s safety, the European Union Council has issued laws regarding the SAR (Specific Absorption Rate), a limit below which users’ health is not jeopardised in any way. Studies and analyses which guarantee the absolute safety of users, whatever their age or conditions of health, have provided the maximum value of 2 W/kg.
BATTERY RECHARGE Rechargeable Ni-MH batteries (Nickel Metalhydrate, or Nickel-Metalhydride) power this phone. Note: only use original batteries and battery-chargers. Ni-MH batteries are subject to the “memo-effect”, that is the progressive loss of power efficiency if they are not recharged correctly. In order to obtain the best results, remember to recharge the battery only after it is completely flat. IMPORTANT Connect the battery-charger only when the battery is installed.
THE Gm882: PRESENTATION AND BASIC FUNCTIONS To switch on the Gm882, after you have inserted a valid SIM card and for a second. correctly connected the battery, press the key Press the same key for one second, to switch off the phone. After the phone has been switched on, (and the PIN code, if required, has been inserted and confirmed with the key ), the Gm882 is in stand-by mode.
FUNCTION OF THE KEYS Key function: to switch the phone ON/OFF, turn the “Mute” function ON/OFF during conversation. Soft keys: to perform the functions indicated by the icons on the display.
SYMBOLS SHOWN ON THE DISPLAY the signal strength of the cellular network (maximum 5 bars); if the name of the GSM network is not displayed, but the bars are shown, you can only make emergency calls shows that a memo for an appointment, or the alarm clock have been enabled a headset or a viva voce device (optional) are connected shows that there are EMS messages that have not been read; if it flashes, it means that there is no more space in the SIM card for new SMS messages.
During a call some icons may appear on the display: indicates call is in progress indicates you have put a call on hold indicates there is a new incoming call while a conversation is in progress. you can put the call in progress on hold and In this case, by pressing answer the new incoming call, you can go on with the conversation in progress and or, by pressing reject the new incoming call.
BASIC FUNCTIONS OF THE PHONE Making a call When the phone is in stand-by mode, key in the number of the receiver . including the area code, and press the key Use the key to delete the last figure or – keeping it pressed for a second – to delete the whole number and go back to the stand-by mode. To key in an international prefix, press the key for a while and digit + (eg. +39 02 xxxxxxx to call Milan from abroad).
Emergency calls Any time – even without a SIM card, but on condition that the phone is in an area served by the GSM network – you can make a (free) emergency call. Key in the number 112 in stand-by mode and press . and confirm with the key . Without the SIM card, press ATTENTION: DO NOT USE THIS SERVICE TO EXCESS Before making any emergency calls, we advise you to read the network operator’s instructions on this service.
MENU The GM882 has two menus through which you can access the various functions and controls which characterise its functioning. The traditional menu, which includes all the functions and controls, and a quick menu, which with few “clicks”, allows you to use the functions you will probably use most often. Traditional menu In stand-by mode press the joystick vertically.
The quick menu In stand-by mode, move the joystick in any direction, without pressing it. The left side of the display will show some icons – each of these allows you to access the basic functions of your Gm882 directly and quickly. The quick menu can be tailored for your Read SMS personal use: when you have enabled it, and the icons are viewed, move the joystick to the right to have access to the list of functions that you can add to the menu.
Writing letters and numbers in the traditional way When writing EMS/SMS messages and e-mails you can use the T9 technology, whereas in other cases, numbers and letters (for example in the phone book) have to be keyed in in the “traditional” way. To obtain the desired character, press the corresponding key several times consecutively until the character you are searching for is viewed on the display; continue like this with the following key.
PHONE BOOK The phone book is one of the basic features of the phone. With the Gm882, besides the memory space available on the SIM card, the phone also provides extra memory for the phone book. You can copy names and numbers from the SIM card onto the phone and vice versa, allowing you to use the phone book whichever SIM card is inserted in the phone.
When you use the internal phone book, you can store further information for each name. For example, you can store the home number, work number, mobile number and e-mail address of one friend. They will be stored in separate files. By moving the joystick left or right you can go from one to another and to call the .
8 SIM phonebook: Barred numbers. Internal phonebook: Options menu 9 SIM phonebook: Service numbers 10SIM phonebook: Options menu If you are using the internal phone book, the Options menu is displayed as follows: 1 Memory in use: this allows you to choose between the internal phone book and the SIM card phone book. 2 Memory status: this provides information on how many numbers can be stored and on the amount of space available.
CALL REGISTER Basic information (the number of the person you are talking to, if available, the time the conversation started, the call type) of the last calls are stored in your phone. Among the incoming calls there are also the unanswered calls. Information refers to calls received while the phone is switched on and connected to the network; some operators can give you information via SMS on calls sent to your number while your phone was switched off or unattainable.
EMS/SMS MESSAGES With the Gm882 you can send and receive traditional SMS text messages that are enriched with two functions – T9 and EMS – which make the editing of the text easier and quicker and allow you to insert pictures, animations and sounds in your messages. T9 is a trademark of Tegic communications inc. and is a technology patented in Europe, the United Kingdom and other countries.
Type (menu 2-1-4-4-3) This network service allows you to convert EMS messages into different formats, such as for example: ISDN and PSTN services, Pager, E-mail, Fax, etc. Change the pre-set value “0_Text” only after having contacted your network operator to make sure these formats can be sent. Extended alphabet (menu 2-1-4-4-4) This function is useful for sending special characters (eg. foreign alphabets) which occupy more space in the memory.
Concatenated messages The phone Gm882 supports concatenated messages. This means that you can edit a text with more than the traditional 160 characters. Before you send the message, it will be automatically split into two or more messages (up to 5) that will be sent to the same addressee. In the text editor on the left of the character counter, which is in the bottom righthand corner, a number is displayed indicating how many messages are needed to send the text you are editing.
If the word written by the phone is not the one required, press to change it with all the available matches, that is, with all the other words you could have written, using the same keys. For example, with the keys 3-4-4-4-8 you can write “digit”, “fight” or “eight”. If the word you were looking for is not among the matches, you can add the words you often use and that T9 does not “know” to the dictionary.
There are two types of EMS objects... ...that is, the predefined objects and the user-defined objects. The former are sent from one phone to another as a code that has been defined by the EMS standard and only take up a very small amount of space within the message itself and these objects are reproduced by the addressee’s phone according to the interpretation that the manufacturer gives them. The user-defined objects are not coded by the EMS standard and are therefore sent complete.
Also in the text messages, the numbers stored in the phone book are automatically replaced by the corresponding name so you can read the name of the person that sent you the message and call them without having to search for their number. Re-reading messages stored in the SIM card... Access menu 2-1-2 (Messages – SMS- Received/Written). The list with the message headings will be displayed, which you can scroll with the joystick and read by pressing the joystick. Deleting a stored message...
GAMES The menu Games (menu 6) gives access to 5 games. Game rules There are 5 games available: Menu 6-1-1 Cards The betting is $50, and your starting capital is $1000. If, with the first five cards, you have no winning combinations, you can change them. The win of each hand, shown in the top right-hand corner, is automatically added to your capital (viewed at the top on the left). At the bottom on the left you can check how many cards are left in the pack.
APPLICATIONS The Gm882 provides a series of software applications that are often useful. Date and time: setting the clock (Time Setup), setting the current date (Date Setup), change the Date format (month/day/year – day/month/year – year/ month/day); enable and disable the Internet time, and set its parameters: Daylight Summer Time and the World Timezone. Calendar: the weekly agenda is viewed on the display.
By moving the joystick up and down you can choose to convert the measure unit indicated at the top to the other or vice versa. Melody Maker With the function Melody Maker of the Gm882, composing your own melodies to use as ringing tones has never been easier. You do not need to know how to compose, or to know the music staff. The lower part of the display shows a piano keyboard (two octaves).
GPRS The GPRS (General Packet Radio Service) is an evolution of the GSM system which keeps the same voice transmission mode but significantly improves the performance of the data transmission using a “packet” system. The Gm882 uses the GPRS system and you can connect it to your computer using the appropriate data cable (optional or included, according to the product type) and this allows a fast transmission of data and connection to the Internet when no connection to the landline is available.
WAP Internet connection with the WAP browser of your Gm882... • You need a SIM card that is enabled for data calls and you must subscribe to the service of the network operator or the service provider. • Search for a place where the signal reception is at its best and stay there; this will definitely improve the quality of your connection. • Press the joystick to access the main menu and scroll through the entries of the menu by pressing the joystick up or down to entry 8 – WAP Browser.
Internet Configuration (menu 8-4) Before you make the first WAP connection, you must set some parameters in the phone – most of them, if they are missing, are given by the service provider. The phone could already be set up for the Internet access; in this case the data needed for the Internet access are already set in the menus: press several to exit the menu and go back to the display in stand-by.
Set-up parameters for WAP connection... 1 Connection Name: This is the name that has been assigned to each of the three available profiles and is displayed in the upper menu level, when the phone asks you to select the profile whose parameters have to be viewed/ changed. If no profile has been set, the three entries are viewed as .
1 Homepage 2 Proxy 3 Circuit Prompt 4 Circuit waiting 5 Page scroll mode 1 Skip 2 Smooth 6 Page scroll speed 1 Fast 2 Medium 3 Slow 7 Timeout key pressing 1 Fast 2 Medium 3 Slow 8 Protection 1 Connection prompt 2 Protection prompt 3 Current certificate 4 CA certificates 5 Coding 1 Check code 2 New code 9 Advanced 1 Show URL 2 Re-start Browser 3 Off-line Services 4 Outgoing mail ? Information on... 1 Openwave 2 Security 1 Schlumberger 2 RSA 1 – Prev. This goes back to the previous page.
6 - Incoming mail The incoming mailbox is shown and new messages are signalled. 7 - Reload This reloads the current WAP page. 8 – Settings 8-1 Homepage If this function has been enabled by the Proxy, it shows the complete address of the homepage and gives you the possibility of changing it (settings of this function contained in the Proxy take priority over those contained in the user’s profile). 8-2 Proxy This allows you to select the WAP Proxy server from those listed.
8-8-3 Current certificate The phone makes use of digital certificates (called “CA”) that are issued by a reliable third party, to authenticate some web sites. By accessing this function, the phone shows information that is available for the certificate used for the current session. 8-8-4 CA Certificates This function displays the list of the CA certificates that are stored in the phone; it is possible to view the main data and to enable or disable them.
ALL FUNCTIONS IN BRIEF Phonebook (menu 1) To use the phone book and other relative functions, see “PHONE BOOK” on page 14. Messaqqges (menu 2) To use the functions for sending and reading EMS/SMS messages (menu 2-1SMS) see “EMS/SMS MESSAGES” on page 18.
Zone Messages (menu 2-5): the broadcast messages are free messages which are sent by some network operators and viewed on the phone display in stand-by mode. The most common shows the name of the area you are in. The submenus available are: Reception: you can choose if you want to view the messages that your phone receives from the network operator (enabling of the service and message content varies from operator to operator).
from abroad, the calls Originated by your mobile; all the international outgoing calls or all the international outgoing calls except for the calls towards your home country. The entry Clear all allows you to clear all filters, and so make and receive any type of call. Change code allows you to change the security code you have to insert before working on Barring functions. Divert (menu 3-6) allows you to divert incoming calls to another phone number.
Wallpaper (4-1-5): use this function to Select (4-1-5-1) the image you want to have on the display in stand-by mode instead of the logo of the network operator (whose name will however appear at the top). With Enable (4-1-5-2) you choose which to have on your display between the image or the operator’s logo. The menu Fonts (menu 4-2) allows you to choose between 3 different types of character (font) for the text on the display: Young, Thin and Classic.
Audio profiles (menu 4-5) The Gm882 has 6 audio profiles which you can use to set the various parameters on ringing tones, vibrating alert and alert tones. At any time, you can enable the audio profile most suitable for the situation you are in, enabling and setting all the different parameters in a single touch. These parameters are already defined when you buy the phone; you can use or change them as you like.
Warning tones (profile X – menu 4): these are tones the Gm882 emits when you receive an SMS message, a Class ero SMS message,when the Battery is Low, and when you switch the Power on or off. In each case there is a menu entry which allows you to set the volume, the tone and the type of alert (ring only, vibrate only, ring and vibrate etc.).
