TERRALUX TLM-R20A Product Specification – Subject to change without notice!

WWW.TERRALUX.COM

5/23/2014!

TLM-R20A

Line Voltage Spot 1200 lm LED Engine

Introduction

The TERRALUX TLM-R20A LED engine is a fully integrated line voltage LED engine designed for spot

lighting applications that require the form factor and performance of a PAR 20 Metal Halide source.

With a diameter equivalent to a PAR 20 lamp and an integrated driver, it makes possible the design

of very compact light fixtures without the burden of a separated driver housing. It is offered with 4

choices of light patterns options and a convenient push button that allows selection of 4 output

modes. A smart thermal design combined with TERRALUX patented LEDSense® closed loop thermal

management helps an easy integration in open or sealed fixtures, for landscape, track lighting and

more.

Features

• PAR 20 diameter (2.5 inch)

• Light output: 1,200 lm

• Efficacy: > 70 lm/W

• 4 lighting levels: 100%, 80%, 55% and 18% easy to select via a push button

• 4 available color temperatures : 2700K, 3000K, 3500K and 4000K

• CRI>80 (CRI>90 available as an option)

• 4 different light patterns: 15°, 23°, 35° and 51°

• Input voltage: 120V AC

• Smooth dimming, compatible with phase-cut 120V dimmers*

• Patented LEDSense® Thermal Management

• L70 > 60,000 hours

• 5-year warranty

• UL Recognized Component

• FCC Class A Compliant

Summary of content (7 pages)

PAGE 1
WWW.TERRALUX.COM TLM-R20A Line V oltage Spot 1200 lm LED Engine Introduction The TERRALUX TLM-R20A LED engine is a fully integrated line voltage LED engine designed for spot lighting applications that require the form factor and performance of a PAR 20 Metal Halide source. With a diameter equivalent to a PAR 20 lamp and an integrated driver, it makes possible the design of very compact light fixtures without the burden of a separated driver housing.
PAGE 2
WWW.TERRALUX.COM Performance Color Temperature 2700K 3000K 3500K 4000K 1180 1220 1270 1280 80 [83] 80 [83] 80 [83] 80 [83] 4 4.9 6.7 12.
PAGE 3
WWW.TERRALUX.
PAGE 4
WWW.TERRALUX.COM LED Sense ® Opera tion, Thermal De-rating and Lumen The TLM-R20A employs TERRALUX’s patented LEDSense® Thermal Management Technology to automatically provide maximum light output in various fixtures and operating conditions while assuring long-term lumen maintenance. LED-Sense® regularly measures the operating temperature and ensures compliance with a pre-programmed temperature and drive-current profile.
PAGE 5
WWW.TERRALUX.COM Tests and Certifications Product Safety Certifications Radio Frequency Emissions Reduction of Hazardous Substances (RoHS) Electro-Static Discharge Power Factor Shock Drop Test Vibration Shipping / Transit Operating Temperature Lumen Maintenance Long Term Operation Reliability Demonstration Test (RDT) Input Voltage Range Dimming UL Standard 8750: LED Light Sources for Use In Lighting Products CSA C22.2 No. 250.
PAGE 6
WWW.TERRALUX.
PAGE 7
WWW.TERRALUX.COM Dimensions Contact Information TERRALUX Inc. 1830 Lefthand Circle Suite B Longmont, CO 80501 Phone: 303-442-4960 Fax: 866-919-2515 OEMsales@TERRALUX.com www.TERRALUX.
