8.1 Bill of Materials
NOTE: All components should be compliant with the European Union Restriction on Use of
Hazardous Substances (RoHS) Directive. Some part numbers may be either leaded or
RoHS. Verify that purchased components are RoHS-compliant. (For more information about
TI's position on RoHS compliance, see the TI web site.)
Table 6. ADS1015EVM/ADS1115EVM Bill of Materials
Item No. Qty Value Ref Des Description Vendor Part Number
1 1 N/A ADS1015/1115 EVM PWB Texas 6511174
Instruments
2 6 0.1μF C1, C2, C3, C4, 16V Ceramic Chip Panasonic ECJ-1VB1C104K
C5, C6 Capacitor X7R
3 2 D1, D2 LED, Red, 0805 Lumex SML-LXT0805IW-TR
4 2 J1A, J3A 20-pin SMT Plug Samtec TSM-110-01-L-DV-P
5 2 J1B, J3B 20-pin SMT Socket Samtec SSW-110-22-F-D-VS-K
6 1 J2A 10-pin SMT Plug Samtec TSM-105-01-L-DV-P
7 1 J2B 10-pin SMT Socket Samtec SSW-105-22-F-D-VS-K
8 0 J4 Header Strip, 6-pin ( )
9 3 JMP1, JMP2, Header Strip, 8-pin ( ) Samtec TSW-104-07-L-D
JMP3
10 2 JMP4, JMP5 Header Strip, 2-pin ( ) Samtec TSW-102-07-L-S
11 1 Q1 N-Channel Enhancement Fairchild NDC7002N
MOSFET
12 2 470 R3, R4 1/10 W, Chip Resistor, ±5% Panasonic ERJ-3GEYJ471V
0603
13 6 1kΩ R1, R2, R5, R6, 1/10 W, Chip Resistor, Panasonic ERJ-3GEYJ102V
R8, R9 ±5%, 0603
14 1 200kΩ R7 1/10 W, Chip Resistor, Panasonic ERJ-3GEYJ204V
±5%, 0603
15 0 RA1 Resistor, Chip Array Four
Independent Bus 100kΩ,
5%, 1/16W, SMD
16 1 S1 DP3T Slide Switch E-Switch EG2305A
17 2 TP1,TP2 PCB Test Point, Large Keystone 5011
Loop, Through-Hole Electronics
18 2 U1,U2 Analog-Digital Converter Texas ADS1115IRUG—ADS1115
Instruments EVM
ADS1015IRUG—ADS1015
EVM
19 1 U3 Texas PCA9306DCT
I
2
C Bus Level Shifter
Instruments
20 1 U4 EEPROM, 1.8V, 256K Microchip 24AA256-I/ST
21 1 U5 Dual Gate Buffer, 3-state Texas SN74LVC2G125DCU
Instruments
22 8 N/A Shorting Blocks Samtec SNT-100-BK-G-H
22
