User's Guide

SLUU497B –December 2011–Revised June 2012

Chipscale-Packaged bq24165, 24166, 24167 Evaluation

Modules

The bq24165, 24166, 24167 evaluation module is a complete charger module for evaluating a compact,

flexible, high-efficiency, USB-friendly, switch-mode charge management solution for single-cell, Li-ion and

Li-polymer batteries used in a wide range of portable applications.

Contents

1 Introduction .................................................................................................................. 2

1.1 bq2416x IC Features .............................................................................................. 2

1.2 bq24165, 24166, 24167 EVM Features ......................................................................... 2

1.3 Schematic ........................................................................................................... 3

1.4 I/O Description ...................................................................................................... 4

1.5 Test Points .......................................................................................................... 4

1.6 Control and Key Parameters Setting ............................................................................ 5

1.7 Recommended Operating Conditions ........................................................................... 5

2 Test Summary ............................................................................................................... 6

2.1 Definitions ........................................................................................................... 6

2.2 Recommended Test Equipment ................................................................................. 6

2.3 Recommended Test Equipment Setup .......................................................................... 7

2.4 Recommended Test Procedure .................................................................................. 8

3 Printed-Circuit Board Layout Guideline ................................................................................. 10

4 Bill of Materials and Board Layout ...................................................................................... 11

4.1 Bill of Materials .................................................................................................... 11

4.2 Board Layout ...................................................................................................... 13

List of Figures

1 bq24165/166/167EVM (HPA741) Schematic............................................................................ 3

2 BAT Load (PR1010) Schematic........................................................................................... 7

3 Original Test Setup for bq24165/166/167 EVM (HPA741) ............................................................ 8

4 Top Assembly Layer ...................................................................................................... 13

5 Top Layer .................................................................................................................. 13

6 Bottom Layer............................................................................................................... 14

7 First Internal Layer ........................................................................................................ 14

8 Second Internal Layer .................................................................................................... 15

List of Tables

1 Bill of Materials - HPA741A ............................................................................................. 11

SLUU497B –December 2011–Revised June 2012 Chipscale-Packaged bq24165, 24166, 24167 Evaluation Modules

Submit Documentation Feedback

Summary of content (20 pages)

PAGE 1
User's Guide SLUU497B – December 2011 – Revised June 2012 Chipscale-Packaged bq24165, 24166, 24167 Evaluation Modules The bq24165, 24166, 24167 evaluation module is a complete charger module for evaluating a compact, flexible, high-efficiency, USB-friendly, switch-mode charge management solution for single-cell, Li-ion and Li-polymer batteries used in a wide range of portable applications. 1 2 3 4 Contents Introduction ...................................................................................
PAGE 2
Introduction 1 Introduction 1.1 bq2416x IC Features www.ti.com The bq24165, 24166, 24167 integrates a synchronous PWM controller, power MOSFETs, input current sensing, high-accuracy current and voltage regulation, charge termination and power path management into a chipscale package. Key integrated circuit (IC) features include: • High-efficiency, fully integrated, NMOS-NMOS, synchronous buck charger with 1.5-MHz frequency • Integrated power FETs for up to 2.
PAGE 3
Introduction www.ti.com 1.3 Schematic Figure 1. bq24165/166/167EVM (HPA741) Schematic NOTE: EVMs with a printed-circuit board label that contain the suffix -X may have been assembled with incorrectly marked ICs. Regardless of the IC’s marking, the EVM was assembled with the correct part number as specified in the EVM bill of material.
PAGE 4
Introduction 1.4 1.5 4 www.ti.
PAGE 5
Introduction www.ti.com 1.6 Control and Key Parameters Setting IC All 1.7 Jum Description per JP1 Default Factory Setting 1-2: FET GATE = BGATE: External PFET's gate tied to BGATE pin and therefore controlled by IC. 1-2 (FET GATE = 2-3: FET GATE = SYS: External PFET's gate tied to SYS and therefore disabled. BGATE) It is recommended that this jumper be changed only when the device is not enabled or in Hi-Z mode so that the PFET's gate is never left open.
PAGE 6
Test Summary 2 www.ti.com Test Summary This procedure describes one test configuration of the HPA741 evaluation board for bench evaluation. 2.1 Definitions The following naming conventions are followed. VXXX : LOAD#: V(TPyyy): V(Jxx): V(TP(XXX)): V(XXX, YYY): I(JXX(YYY)): Jxx(BBB): JPx ON : JPx OFF: JPx (-YY-) Measure: → A,B Observe → A,B External voltage supply name (VIN, VUSB) External load name Voltage at internal test point TPyyy. For example, V(TP12) means the voltage at TP12.
PAGE 7
Test Summary www.ti.com Figure 2. BAT Load (PR1010) Schematic 2.2.3 Load #2 Between SYS and GND Although not required, a resistive load capable of sinking up to 3 A can be used. 2.2.4 Meters Four equivalent voltage meters (VMx) and two equivalent current meters (CMx) are required. The current meters must be able to measure at least 3-A current. 2.3 Recommended Test Equipment Setup 1. For all power connections, use short, twisted-pair wires of appropriate gauge wire for the amount of the current. 2.
PAGE 8
Test Summary www.ti.com CM#1 VM#1 + + PS #1 V A - IIN PS#2 - ICHRG BAT_Load + A CM#2 V + - VM#3 - V VM#2 V + + VM#4 Figure 3. Original Test Setup for bq24165/166/167 EVM (HPA741) 2.4 Recommended Test Procedure The following test procedure may be useful for evaluating the charger IC outside of a real system, if no battery is available to connect to the output and a simulated battery is needed. 2.4.1 Charge Voltage and Current Regulation of IN 1. Ensure that the Section 2.
PAGE 9
Test Summary www.ti.com 2.4.2 Charge Voltage and Current Regulation of USB 1. Ensure that the Section 2.3 steps are followed. 2. Move JP2 (CE1 or CE) = HI and JP6 = HI. 3. Connect the output of Power Supply number 1 (PS1) in series with current meter (multimeter) number 1 (CM1) to J4 and J8 or J6 (USB, GND). 4. Connect voltage meter 1 (VM1) across J4 or TP2 and J8 or TP5 (USB, GND). 5. With PS2 disabled, turn on PS1. 6. Measure: Measure on VM3 → V(J5/TP4(SYS),J9(GND)) = 4.
PAGE 10
Printed-Circuit Board Layout Guideline 3 www.ti.com Printed-Circuit Board Layout Guideline 1. To obtain optimal performance, the power input capacitors, connected from the PMID input to PGND, must be placed as close as possible to the bq2416x. 2. Place 4.7-µF input capacitor as close to PMID pin and PGND pin as possible to make high-frequency current loop area as small as possible.
PAGE 11
Bill of Materials and Board Layout www.ti.com 4 Bill of Materials and Board Layout 4.1 Bill of Materials Table 1. Bill of Materials - HPA741A Count RefDes Value Description Size Part Number MFR 0 C1, C6 Open Capacitor, Ceramic 805 Std Std 2 C2, C7 1.0µF Capacitor, Ceramic, 25V, X5R, 10% 603 Std Std 2 2 C3, C8 4.7µF Capacitor, Ceramic, 25V, X5R, 10% 805 Std Std 1 1 1 C4 10µF Capacitor, Ceramic, 10V, X5R, 20% 603 Std Std 1 1 1 C5 47µF Capacitor, Ceramic, 6.
PAGE 12
Bill of Materials and Board Layout www.ti.com Table 1. Bill of Materials - HPA741A (continued) Count RefDes Value Description Size Part Number MFR 0 U1 BQ24165YFF IC, 2.5A, Dual-Input, Single Cell Switch-mode Li-Ion BATTERY CHARGER with BGA BQ24165YFF TI 1 0 U1 BQ24166YFF IC, 2.5A, Dual-Input, Single Cell Switch-mode Li-Ion BATTERY CHARGER with BGA BQ24166YFF TI 0 0 1 U1 BQ24167YFF IC, 2.
PAGE 13
Bill of Materials and Board Layout www.ti.com 4.2 Board Layout TEXAS INSTRUMENTS Figure 4. Top Assembly Layer Figure 5.
PAGE 14
Bill of Materials and Board Layout www.ti.com Figure 6. Bottom Layer Figure 7.
PAGE 15
Bill of Materials and Board Layout www.ti.com Figure 8.
PAGE 16
