SLUSAL8C –JUNE 2011–REVISED SEPTEMBER 2012

Qi Compliant Wireless Power Transmitter Manager

Check for Samples: bq500210

FEATURES

APPLICATIONS

• Intelligent Control of the Power Transfer • WPC 1.0.2 Compliant Wireless Chargers for:

between Base Station and Mobile Device

– Mobile and Smart Phones

• Conforms to the Wireless Power Consortium

– MP3 Players

(WPC) Wireless Power Transfer 1.0.2

– Global Positioning Devices

Specification

– Digital Cameras

• Digital Demodulation Significantly Simplifies

• Other Wireless Power Transmitters in:

Solution Over bq500110

– Cars and Other Vehicles

• Improved Parasitic Metal Object Detection

– Hermetically Sealed Devices, Tools, and

(PMOD) Promotes Safety During Wireless

Appliances

Power Transfer

– Furniture Built-In Wireless Chargers

• Enhanced Charge Status Indicator

– Toy Power Supplies and Chargers

• Operating Modes Status Indicators

• See www.ti.com/wirelesspower for More

– Standby

Information on TI's Wireless Charging

– Power Transfer (visual and audio)

Solutions

– Charge Complete

– Fault

• Over Temperature Protection

DESCRIPTION

The bq500210 is a second generation Wireless Power dedicated digital controller that integrates the logic

functions required to control Wireless Power Transfer in a single channel WPC compliant contactless charging

base station. The bq500210 is an intelligent device that periodically pings the surrounding environment for

available devices to be powered, monitors all communication from the device being wirelessly powered, and

adjusts power applied to the transmitter coil per feedback received from the powered device. The bq500210 also

manages the fault conditions associated with the power transfer and controls the operating modes status

indicator. The bq500210 supports improved Parasitic Metal Object Detection (PMOD). The controller in real time

analyzes the efficiency of the established power transfer using Rectified Power Packets and protects itself and

the power receiver from excessive power loss and heat associated with parasitic metal objects placed in the

power transfer path.

The bq500210 is available in an area saving 48-pin, 7mm x 7mm QFN package and operates over a temperature

range from –40°C to 110°C.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.
