SCHS228B − SEPTEMBER 1998 − REVISED MARCH 2004
1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
D AC Types Feature 1.5-V to 5.5-V Operation
and Balanced Noise Immunity at 30% of the
Supply Voltage
D Speed of Bipolar F, AS, and S, With
Significantly Reduced Power Consumption
D Greater Noise Immunity Than Standard
Inverters
D Operates With Much Slower Than Standard
Input Rise and Fall Slew Rates
D Balanced Propagation Delays
D ±24-mA Output Drive Current
− Fanout to 15 F Devices
D SCR Latchup-Resistant CMOS Process and
Circuit Design
D Exceeds 2-kV ESD Protection Per
MIL-STD-883, Method 3015
description/ordering information
The CD74AC14 contains six independent inverters. This device performs the Boolean function Y = A.
Each circuit functions as an independent inverter, but because of the Schmitt action, the inverters have different
input threshold levels for positive-going (V
T+
) and negative-going (V
T−
) signals.
ORDERING INFORMATION
T
A
PACKAGE
†
ORDERABLE
PART NUMBER
TOP-SIDE
MARKING
PDIP − E Tube CD74AC14E CD74AC14E
−55°C to 125°C
SOIC − M
Tube CD74AC14M
AC14M
−55 C to 125 C
SOIC − M
Tape and reel CD74AC14M96
AC14M
†
Package drawings, standard packing quantities, thermal data, symbolization, and PCB design guidelines
are available at www.ti.com/sc/package.
FUNCTION TABLE
(each inverter)
INPUT
A
OUTPUT
Y
H L
L H
logic diagram, each inverter (positive logic)
YA
Copyright  2004, Texas Instruments Incorporated
    !"   #!$% &"'
&!   #" #" (" "  ") !"
&& *+' &! #", &"  ""%+ %!&"
",  %% #""'
1
2
3
4
5
6
7
14
13
12
11
10
9
8
1A
1Y
2A
2Y
3A
3Y
GND
V
CC
6A
6Y
5A
5Y
4A
4Y
E OR M PACKAGE
(TOP VIEW)
