www.ti.com

FEATURES DESCRIPTION

APPLICATIONS

SCLA0

GND

Output

Buffer

Power-Down

Control Logic

Resistor

Network

Ref (+) Ref (−)

10-Bit

DAC

Control

Logic

DAC

Power-On

Reset

OUT

SDA

DAC6571

SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005

+2.7 V to +5.5 V, I

C INTERFACE, VOLTAGE OUTPUT,

10-BIT DIGITAL-TO-ANALOG CONVERTER

• Micropower Operation: 125 µ A @ 3 V

The DAC6571 is a low-power, single-channel, 10-bit

• Fast Update Rate: 188 kSPS

buffered voltage output digital-to-analog converter

(DAC). Its on-chip precision output amplifier allows

• Power-On Reset to Zero

rail-to-rail output swing to be achieved. The DAC6571

• +2.7-V to +5.5-V Power Supply

utilizes an I

C-compatible, two-wire serial interface

• Specified Monotonic by Design

that operates at clock rates up to 3.4 MBPS with

• I

C™ Interface up to 3.4 MBPS

address support of up to two DAC6571s on the same

data bus.

• On-Chip Output Buffer Amplifier, Rail-to-Rail

Operation

The output voltage range of the DAC is 0 V to V

• Double-Buffered Input Register

The DAC6571 incorporates a power-on-reset circuit

• Address Support for up to Two DAC6571s

that ensures that the DAC output powers up at zero

volts and remains there until a valid write to the

• Small SOT23-6 Package

device takes place. The DAC6571 contains a

• Operation From –40 ° C to +105 ° C

power-down feature, accessed via the internal control

device to 50 nA at 5 V.

• Process Control

The low power consumption of this part in normal

• Data Acquistion Systems

operation makes it ideally suited for portable battery

• Closed-Loop Servo Control

operated equipment. The power consumption is less

• PC Peripherals than 0.7 mW at V

= 5 V reducing to 1 µ W in

power-down mode.

• Portable Instrumentation

The DAC7571/6571/5571 are 12/10/8-bit,

single-channel I

C DACs from the same family. The

DAC7574/6574/5574 and DAC7573/6573/5573 are

12/10/8-bit, quad-channel I

C DACs. Also see the

DAC8571/8574 for single/quad-channel, 16-bit I

DACs.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas

Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

C is a trademark of Philips Corporation.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

Summary of content (25 pages)

PAGE 1
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 +2.7 V to +5.5 V, I2C INTERFACE, VOLTAGE OUTPUT, 10-BIT DIGITAL-TO-ANALOG CONVERTER FEATURES DESCRIPTION • • • • • • • The DAC6571 is a low-power, single-channel, 10-bit buffered voltage output digital-to-analog converter (DAC). Its on-chip precision output amplifier allows rail-to-rail output swing to be achieved. The DAC6571 utilizes an I2C-compatible, two-wire serial interface that operates at clock rates up to 3.
PAGE 2
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage. ESD damage can range from subtle performance degradation to complete device failure.
PAGE 3
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 ELECTRICAL CHARACTERISTICS VDD = +2.7 V to +5.5 V; RL = 2 kΩ to GND; CL = 200 pF to GND; all specifications –40°C to +105°C unless otherwise noted. PARAMETER DAC6571 CONDITIONS MIN TYP MAX UNITS STATIC PERFORMANCE (1) Resolution 10 Bits Relative accuracy Differential nonlinearity Assured monotonic by design Zero code error Full-scale error All ones loaded to DAC register ±2 LSB ±0.5 LSB 5 20 mV –0.15 –1.
PAGE 4
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TIMING CHARACTERISTICS SYMBOL PARAMETER TEST CONDITIONS fSCL SCL Clock Frequency MIN MAX UNITS Standard mode 100 kHz Fast mode 400 kHz High-speed mode, CB – 100 pF max 3.4 MHz 1.7 MHz High-Speed mode, CB – 400 pF max tBUF tHD; tSTA tLOW tHIGH tSU; tSTA tSU; tDAT tHD; tDAT tRCL Bus Free Time Between a STOP and START Condition Standard mode 4.7 µs Fast mode 1.
PAGE 5
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TIMING CHARACTERISTICS (continued) SYMBOL PARAMETER TEST CONDITIONS tSU; tSTO Setup Time for STOP Condition Standard mode 4.0 µs Fast mode 600 ns High-speed mode 160 ns CB Capacitive Load for SDA and SCL tSP Pulse Width of Spike Suppressed VNH Noise Margin at the HIGH Level for Each Connected Device (Including Hysteresis) MIN TYP MAX UNITS 400 pF Fast mode 50 ns High-speed mode 10 ns Standard mode 0.
PAGE 6
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TYPICAL CHARACTERISTICS: VDD = +5 V (continued) At TA = +25°C, +VDD = +5 V, unless otherwise noted.
PAGE 7
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TYPICAL CHARACTERISTICS: VDD = +5 V (continued) At TA = +25°C, +VDD = +5 V, unless otherwise noted. SUPPLY CURRENT vs SUPPLY VOLTAGE POWER-DOWN CURRENT vs SUPPLY VOLTAGE 300 90 80 200 70 150 IDD (nA) I DD − Supply Current − µ A 100 250 100 60 +105°C 50 –40°C 40 30 50 20 0 2.7 3.2 3.7 4.2 4.7 VDD − Supply Voltage − V 5.2 5.7 +25°C 10 0 2.7 3.2 3.7 4.2 4.7 5.2 5.7 VDD (V) Figure 11. Figure 12.
PAGE 8
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TYPICAL CHARACTERISTICS: VDD = +5 V (continued) At TA = +25°C, +VDD = +5 V, unless otherwise noted. FULL-SCALE SETTLING TIME HALF-SCALE SETTLING TIME CLK (5V/div) CLK (5V/div) VOUT (1V/div) Full−Scale Code Change 1023 to 0 Output Loaded with 2 k and 200 pF to GND Half−Scale Code Change 256 to 768 Output Loaded with 2kΩ and 200pF to GND VOUT (1V/div) Time 1 s/div Time (1µs/div) Figure 15. Figure 16.
PAGE 9
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TYPICAL CHARACTERISTICS: VDD = +2.7 V At TA = +25°C, +VDD = +2.7 V, unless otherwise noted. LINEARITY ERROR AND DIFFERENTIAL LINEARITY ERROR vs CODE (–40°C) LINEARITY ERROR AND DIFFERENTIAL LINEARITY ERROR vs CODE (+25°C) 2 VDD = 2.7 V at 25°C 1 LE − LSB LE − LSB 0 −1 0 −1 −2 −2 0.5 0.5 DLE − LSB DLE − LSB 2 VDD = 2.7 V at −40°C 1 0.25 0 −0.25 0.25 0 −0.25 −0.5 −0.
PAGE 10
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TYPICAL CHARACTERISTICS: VDD = +2.7 V (continued) At TA = +25°C, +VDD = +2.7 V, unless otherwise noted. IDD HISTOGRAM SOURCE AND SINK CURRENT CAPABILITY 3 2500 VDD = 2.
PAGE 11
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 TYPICAL CHARACTERISTICS: VDD = +2.7 V (continued) At TA = +25°C, +VDD = +2.7 V, unless otherwise noted. FULL-SCALE SETTLING TIME HALF-SCALE SETTLING TIME CLK (2.7V/div) CLK (2.7V/div) Full−Scale Code Change 3FFH to 000H Output Loaded with 2kΩ and 200pF to GND VOUT (1V/div) Half−Scale Code Change 256 to 768 VOUT (1V/div) Output Loaded with 2 kΩ and 200 pF to GND Time (1 µs/div) Time (1µs/div) Figure 33. Figure 34.
PAGE 12
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 THEORY OF OPERATION D/A SECTION The architecture of the DAC6571 consists of a string DAC followed by an output buffer amplifier. Figure 39 shows a generalized block diagram of the DAC architecture. VDD 50 k 50 k 70 k _ Ref+ Resistor String Ref− DAC Register + VOUT GND Figure 39.
PAGE 13
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 THEORY OF OPERATION (continued) Specification: standard mode (100 kBPS), fast mode (400 kBPS), and high-speed mode (3.4 MBPS). The data transfer protocol for standard and fast modes is exactly the same; therefore, they are referred to as F/S-mode in this document. The protocol for high-speed mode is different from the F/S-mode, and it is referred to as HS-mode.
PAGE 14
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 THEORY OF OPERATION (continued) SDA SCL Data Line Stable; Data Valid Change of Data Allowed Figure 42. Bit Transfer on the I2C Bus Data Output by Transmitter Not Acknowledge Data Output by Receiver Acknowledge SCL From Master 1 2 8 9 S Clock Pulse for Acknowledgement START Condition Figure 43.
PAGE 15
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 THEORY OF OPERATION (continued) DAC6571 I2C Update Sequence The DAC6571 requires a start condition, a valid I2C address, a control-MSB byte, and an LSB byte for a single update. After the receipt of each byte, the DAC6571 acknowledges by pulling the SDA line low during the high period of a single clock pulse. A valid I2C address selects the DAC6571.
PAGE 16
DAC6571 www.ti.
PAGE 17
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 POWER-ON RESET The DAC6571 contains a power-on reset circuit that controls the output voltage during power up. On power up, the DAC register is filled with zeros and the output voltage is 0 V. It remains at a zero-code output until a valid write sequence is made to the DAC. This configuration is useful in applications where it is important to know the state of the DAC output while it is in the process of powering up.
PAGE 18
DAC6571 www.ti.com SLAS406B – DECEMBER 2003 – REVISED AUGUST 2005 OUTPUT VOLTAGE STABILITY The DAC6571 exhibits excellent temperature stability of 5 ppm/°C typical output voltage drift over the specified temperature range of the device. This enables the output voltage to stay within a ±25–µV window for a ±1°C ambient temperature change. Combined with good dc noise performance and true 10-bit differential linearity, the DAC6571 becomes a perfect choice for closed-loop control applications.
PAGE 19
PACKAGE OPTION ADDENDUM www.ti.
PAGE 20
PACKAGE OPTION ADDENDUM www.ti.
PAGE 21
PACKAGE MATERIALS INFORMATION www.ti.com 8-Jul-2011 TAPE AND REEL INFORMATION *All dimensions are nominal Device Package Package Pins Type Drawing SPQ Reel Reel A0 Diameter Width (mm) (mm) W1 (mm) DAC6571IDBVR SOT-23 DBV 6 3000 178.0 9.0 DAC6571IDBVT SOT-23 DBV 6 250 178.0 9.0 Pack Materials-Page 1 B0 (mm) K0 (mm) P1 (mm) W Pin1 (mm) Quadrant 3.23 3.17 1.37 4.0 8.0 Q3 3.23 3.17 1.37 4.0 8.
PAGE 22
PACKAGE MATERIALS INFORMATION www.ti.com 8-Jul-2011 *All dimensions are nominal Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm) DAC6571IDBVR SOT-23 DBV 6 3000 180.0 180.0 18.0 DAC6571IDBVT SOT-23 DBV 6 250 180.0 180.0 18.
