DRV2605
IN/Trigger
2.5 V – 5.5 V
OUT+
OUT-
EN
ROM
REG
C
VREG
DRV2605
www.ti.com
SLOS774A –DECEMBER 2012–REVISED DECEMBER 2012
Haptic Driver for ERM and LRA with Built-In Library and Smart Loop Architecture
Check for Samples: DRV2605
1
FEATURES
DESCRIPTION
The DRV2605 is designed to give extremely flexible
• Flexible Haptic/Vibra Driver
haptic control of ERM and LRA actuators over a
– LRA (Linear Resonance Actuator)
shared I
2
C compatible bus. This relieves the host
– ERM (Eccentric Rotating Mass)
processor from ever generating pulse-width
modulated (PWM) drive signals, saving both costly
• I
2
C Controlled Digital Playback Engine
timer interrupts and hardware pins.
– Royalty-Free Integrated Immersion Library
The DRV2605 gives royalty-free access to an
– Real-Time Playback Mode via I
2
C
extensive integrated library (100+ effects) from
• Smart Loop Architecture
(1)
Immersion for ERM and LRA. This eliminates the
– Automatic Overdrive/Braking (ERM/LRA)
need to design haptic waveforms.
– Automatic Resonance Tracking (LRA)
Additionally, the real-time playback mode allows the
– Automatic Actuator Diagnostic (ERM/LRA)
host processor to bypass the library playback engine
and play waveforms directly from the host via I2C.
– Automatic Level Calibration (ERM/LRA)
The DRV2605 also contains a smart loop
• Audio To Haptics Mode
architecture, which allows effortless auto resonant
• Optional PWM Input with 0% to 100% Duty
drive for LRA as well as feedback-optimized ERM
Cycle Control Range
drive. This feedback gives automatic overdrive and
• Optional Analog Input Control
braking, which creates a simplified input waveform
paradigm as well as reliable motor control and
• Optional Hardware Trigger Pin
consistent motor performance. The audio-to-haptics
• Efficient Output Drive
mode automatically converts an audio input signal to
• Fast Start Up Time
meaningful haptic effects.
• Constant Acceleration Over Supply Voltage
The DRV2605 features a trinary-modulated output
• 1.8 V Compatible, VDD Tolerant Digital Pins
stage, providing greater efficiency than linear-based
output drivers. The 9-ball WCSP footprint, flexible
• Available in a 9-Ball, 0.5 mm Pitch WCSP
operation, and low component count make the
(1)
Patent pending control algorithm
DRV2605 the ideal choice for portable and touch-
enabled vibratory and haptic applications.
