DRV8803

www.ti.com

SLVSAW5B –JULY 2011–REVISED FEBRUARY 2012

QUAD LOW-SIDE DRIVER IC

Check for Samples: DRV8803

FEATURES

• 4-Channel Protected Low-Side Driver

• 8.2-V to 60-V Operating Supply Voltage Range

– Four NMOS FETs With Overcurrent • Thermally Enhanced Surface Mount Package

Protection

APPLICATIONS

– Integrated Inductive Catch Diodes

• Relay Drivers

– Parallel Interface

• Unipolar Stepper Motor Drivers

• DW Package: 1.5-A (Single Channel On) /

800-mA (Four Channels On) Maximum Drive

• Solenoid Drivers

Current per Channel (at 25°C)

• General Low-Side Switch Applications

• PWP Package: 2-A (Single Channel On) /

1-A (Four Channels On) Maximum Drive

Current per Channel (at 25°C, With Proper PCB

Heatsinking)

DESCRIPTION

The DRV8803 provides a 4-channel low side driver with overcurrent protection. It has built-in diodes to clamp

turn-off transients generated by inductive loads and can be used to drive unipolar stepper motors, DC motors,

relays, solenoids, or other loads.

In the SOIC (DW) package, the DRV8803 can supply up to 1.5-A (one channel on) or 800-mA (all channels on)

continuous output current per channel, at 25°C. In the HTSSOP (PWP) package, it can supply up to 2-A (one

channel on) or 1-A (four channels on) continuous output current per channel, at 25°C with proper PCB

heatsinking.

The device is controlled via a simple parallel interface.

Internal shutdown functions are provided for over current protection, short circuit protection, under voltage

lockout and overtemperature and faults are indicated by a fault output pin.

The DRV8803 is available in a 20-pin thermally-enhanced SOIC package and a 16-pin HTSSOP package (Eco-

friendly: RoHS & no Sb/Br).

ORDERING INFORMATION

(1)

ORDERABLE PART TOP-SIDE

PACKAGE

(2)

NUMBER MARKING

Reel of 2000 DRV8803DWR DRV8803

(SOIC) - DW

Tube of 25 DRV8803DW DRV8803

Reel of 2000 DRV8803PWPR DRV8803

(HTSSOP) - PWP

Tube of 90 DRV8803PWP DRV8803

(1) For the most current packaging and ordering information, see the Package Option Addendum at the end of this document, or see the TI

web site at www.ti.com.

(2) Package drawings, thermal data, and symbolization are available at www.ti.com/packaging.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2PowerPAD is a trademark of texas Instruments.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

Summary of content (20 pages)

PAGE 1
DRV8803 www.ti.com SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 QUAD LOW-SIDE DRIVER IC Check for Samples: DRV8803 FEATURES 1 • 2 • • 4-Channel Protected Low-Side Driver – Four NMOS FETs With Overcurrent Protection – Integrated Inductive Catch Diodes – Parallel Interface DW Package: 1.
PAGE 2
DRV8803 SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 www.ti.com DEVICE INFORMATION Functional Block Diagram 8.2V – 60V Internal Reference Regs UVLO VM nENBL LS Gate Drive OCP & Gate Drive RESET 8.2V – 60V Optional Zener Int.
PAGE 3
DRV8803 www.ti.com SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 Table 1. TERMINAL FUNCTIONS PIN (HTSSOP) I/O (1) 5, 6, 7, 14, 15, 16 5, 12, PPAD - Device ground All pins must be connected to GND. 1 1 - Device power supply Connect to motor supply (8.2 V - 60 V).
PAGE 4
DRV8803 SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 www.ti.com ABSOLUTE MAXIMUM RATINGS over operating free-air temperature range (unless otherwise noted) (1) (2) VALUE UNIT VM Power supply voltage range –0.3 to 65 V VOUTx Output voltage range –0.3 to 65 V VCLAMP Clamp voltage range –0.3 to 65 V Output current 20 mA Peak clamp diode current 2 A DC or RMS clamp diode current 1 A –0.5 to 7 V –0.
PAGE 5
DRV8803 www.ti.com SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 RECOMMENDED OPERATING CONDITIONS MIN VM Power supply voltage range VCLAMP Output clamp voltage range (1) IOUT (1) (2) NOM MAX UNIT 8.2 60 V 0 60 V Continuous output current, single channel on, TA = 25°C, SOIC package (2) 1.5 Continuous output current, four channels on, TA = 25°C, SOIC package (2) 0.8 Continuous output current, single channel on, TA = 25°C, HTSSOP package (2) 1.
PAGE 6
DRV8803 SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 www.ti.com TIMING REQUIREMENTS over operating free-air temperature range (unless otherwise noted) (1) NO. (1) PARAMETER DESCRIPTION MIN MAX UNIT 1 tOE(ENABLE) Enable time, nENBL to output low 50 ns 2 tPD(L-H) Propogation delay time, INx to OUTx, low to high 200 ns 3 tPD(H-L) Propogation delay time, INx to OUTx, high to low 200 - tRESET RESET pulse width 20 ns µs Not production tested. nENBL INx OUTx 1 2 3 Figure 1.
PAGE 7
DRV8803 www.ti.com SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 FUNCTIONAL DESCRIPTION Output Drivers The DRV8803 contains four protected low-side drivers. Each output has an integrated clamp diode connected to a common pin, VCLAMP. VCLAMP can be connected to the main power supply voltage, VM. It can also be connected to a zener or TVS diode to VM, allowing the switch voltage to exceed the main supply voltage VM.
PAGE 8
DRV8803 SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 www.ti.com Protection Circuits The DRV8803 is fully protected against undervoltage, overcurrent and overtemperature events. Overcurrent Protection (OCP) An analog current limit circuit on each FET limits the current through the FET by removing the gate drive. If this analog current limit persists for longer than the tOCP deglitch time (approximately 3.5 µs), the driver will be disabled and the nFAULT pin will be driven low.
PAGE 9
DRV8803 www.ti.com SLVSAW5B – JULY 2011 – REVISED FEBRUARY 2012 THERMAL INFORMATION Thermal Protection The DRV8803 has thermal shutdown (TSD) as described above. If the die temperature exceeds approximately 150°C, the device will be disabled until the temperature drops to a safe level. Any tendency of the device to enter TSD is an indication of either excessive power dissipation, insufficient heatsinking, or too high an ambient temperature.
PAGE 10
PACKAGE OPTION ADDENDUM www.ti.
PAGE 11
PACKAGE OPTION ADDENDUM www.ti.
PAGE 12
PACKAGE MATERIALS INFORMATION www.ti.com 19-Dec-2013 TAPE AND REEL INFORMATION *All dimensions are nominal Device Package Package Pins Type Drawing SPQ Reel Reel A0 Diameter Width (mm) (mm) W1 (mm) B0 (mm) K0 (mm) P1 (mm) W Pin1 (mm) Quadrant DRV8803DWR SOIC DW 20 2000 330.0 24.4 10.8 13.3 2.7 12.0 24.0 Q1 DRV8803PWPR HTSSOP PWP 16 2000 330.0 12.4 6.9 5.6 1.6 8.0 12.
PAGE 13
PACKAGE MATERIALS INFORMATION www.ti.com 19-Dec-2013 *All dimensions are nominal Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm) DRV8803DWR SOIC DW 20 2000 367.0 367.0 45.0 DRV8803PWPR HTSSOP PWP 16 2000 367.0 367.0 35.
PAGE 14
PAGE 15
PAGE 16
PAGE 17
PAGE 18
PAGE 19
PAGE 20
IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
