RM46L852
SPNS185C –SEPTEMBER 2012–REVISED JUNE 2015
RM46L852 16- and 32-Bit RISC Flash Microcontroller
1 Device Overview
1.1 Features
1
• High-Performance Microcontroller for Safety- • Enhanced Timing Peripherals for Motor Control
Critical Applications
– 7 Enhanced Pulse Width Modulator (ePWM)
– Dual CPUs Running in Lockstep Modules
– ECC on Flash and RAM Interfaces – 6 Enhanced Capture (eCAP) Modules
– Built-In Self-Test (BIST) for CPU and On-chip – 2 Enhanced Quadrature Encoder Pulse (eQEP)
RAMs Modules
– Error Signaling Module With Error Pin • Two Next Generation High-End Timer (N2HET)
Modules
– Voltage and Clock Monitoring
– N2HET1: 32 Programmable Channels
• ARM
®
Cortex
®
-R4F 32-Bit RISC CPU
– N2HET2: 18 Programmable Channels
– 1.66 DMIPS/MHz With 8-Stage Pipeline
– 160-Word Instruction RAM Each With Parity
– FPU With Single- and Double-Precision
Protection
– 12-Region Memory Protection Unit (MPU)
– Each N2HET Includes Hardware Angle
– Open Architecture With Third-Party Support
Generator
• Operating Conditions
– Dedicated High-End Timer Transfer Unit (HTU)
– Up to 220-MHz System Clock
for Each N2HET
– Core Supply Voltage (VCC): 1.14 to 1.32 V
• Two 12-Bit Multibuffered Analog-to-Digital
– I/O Supply Voltage (VCCIO): 3.0 to 3.6 V
Converter (MibADC) Modules
• Integrated Memory
– ADC1: 24 Channels
– 1.25MB of Program Flash With ECC
– ADC2: 16 Channels Shared With ADC1
– 192KB of RAM With ECC
– 64 Result Buffers Each With Parity Protection
– 64KB of Flash for Emulated EEPROM With
• Multiple Communication Interfaces
ECC
– 10/100 Mbps Ethernet MAC (EMAC)
• 16-Bit External Memory Interface (EMIF)
• IEEE 802.3 Compliant (3.3-V I/O Only)
• Common Platform Architecture
• Supports MII, RMII, and MDIO
– Consistent Memory Map Across Family
– USB
– Real-Time Interrupt (RTI) Timer (OS Timer)
• 2-Port USB Host Controller
– 128-Channel Vectored Interrupt Module (VIM)
• One Full-Speed USB Device Port
– 2-Channel Cyclic Redundancy Checker (CRC)
– Three CAN Controllers (DCANs)
• Direct Memory Access (DMA) Controller
• 64 Mailboxes Each With Parity Protection
– 16 Channels and 32 Peripheral Requests
• Compliant to CAN Protocol Version 2.0A and
– Parity Protection for Control Packet RAM
2.0B
– DMA Accesses Protected by Dedicated MPU
– Inter-Integrated Circuit (I
2
C)
• Frequency-Modulated Phase-Locked Loop
– Three Multibuffered Serial Peripheral Interface
(FMPLL) With Built-In Slip Detector
(MibSPI) Modules
• Separate Nonmodulating PLL
• 128 Words Each With Parity Protection
• IEEE 1149.1 JTAG, Boundary Scan and ARM
• 8 Transfer Groups
CoreSight™ Components
– Up to Two Standard Serial Peripheral Interface
• Advanced JTAG Security Module (AJSM)
(SPI) Modules
• Calibration Capabilities
– Two UART (SCI) Interfaces, One With Local
– Parameter Overlay Module (POM)
Interconnect Network (LIN 2.1) Interface
• 16 General-Purpose Input/Output (GPIO) Pins
Support
Capable of Generating Interrupts
• Packages
– 144-Pin Quad Flatpack (PGE) [Green]
– 337-Ball Grid Array (ZWT) [Green]
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
