LM2596
www.ti.com
SNVS124C –NOVEMBER 1999–REVISED APRIL 2013
LM2596 SIMPLE SWITCHER
®
Power Converter 150 kHz
3A Step-Down Voltage Regulator
Check for Samples: LM2596
1
FEATURES
DESCRIPTION
The LM2596 series of regulators are monolithic
23
• 3.3V, 5V, 12V, and Adjustable Output Versions
integrated circuits that provide all the active functions
• Adjustable Version Output Voltage Range,
for a step-down (buck) switching regulator, capable of
1.2V to 37V ±4% Max Over Line and Load
driving a 3A load with excellent line and load
Conditions
regulation. These devices are available in fixed output
voltages of 3.3V, 5V, 12V, and an adjustable output
• Available in TO-220 and TO-263 Packages
version.
• Ensured 3A Output Load Current
Requiring a minimum number of external
• Input Voltage Range Up to 40V
components, these regulators are simple to use and
• Requires Only 4 External Components
include internal frequency compensation , and a
• Excellent Line and Load Regulation
fixed-frequency oscillator.
Specifications
The LM2596 series operates at a switching frequency
• 150 kHz Fixed Frequency Internal Oscillator
of 150 kHz thus allowing smaller sized filter
• TTL Shutdown Capability
components than what would be needed with lower
frequency switching regulators. Available in a
• Low Power Standby Mode, I
Q
Typically 80 μA
standard 5-lead TO-220 package with several
• High Efficiency
different lead bend options, and a 5-lead TO-263
• Uses Readily Available Standard Inductors
surface mount package.
• Thermal Shutdown and Current Limit
A standard series of inductors are available from
Protection
several different manufacturers optimized for use with
the LM2596 series. This feature greatly simplifies the
APPLICATIONS
design of switch-mode power supplies.
• Simple High-Efficiency Step-Down (Buck)
Other features include a ensured ±4% tolerance on
Regulator
output voltage under specified input voltage and
output load conditions, and ±15% on the oscillator
• On-Card Switching Regulators
frequency. External shutdown is included, featuring
• Positive to Negative Converter
typically 80 μA standby current. Self protection
features include a two stage frequency reducing
current limit for the output switch and an over
temperature shutdown for complete protection under
fault conditions.
(1)
(1) † Patent Number 5,382,918.
Typical Application
(Fixed Output Voltage Versions)
1
