LM2743

PULL-UP

LM2743

www.ti.com

SNVS276G –APRIL 2004–REVISED MARCH 2013

LM2743 Low Voltage N-Channel MOSFET Synchronous Buck Regulator Controller

Check for Samples: LM2743

FEATURES

DESCRIPTION

The LM2743 is a high-speed synchronous buck

• Power Stage Input Voltage from 1V to 16V

regulator controller with an accurate feedback voltage

• Control Stage Input Voltage from 3V to 6V

accuracy of ±2%. It can provide simple down

• Output Voltage Adjustable down to 0.6V

conversion to output voltages as low as 0.6V. Though

the control sections of the IC are rated for 3 to 6V,

• Power Good Flag and Shutdown

the driver sections are designed to accept input

• Output Over-Voltage and Under-Voltage

supply rails as high as 16V. The use of adaptive non-

Detection

overlapping MOSFET gate drivers helps avoid

• ±2% Feedback Voltage Accuracy Over

potential shoot-through problems while maintaining

Temperature

high efficiency. The IC is designed for the more cost-

effective option of driving only N-channel MOSFETs

• Low-Side Adjustable Current Sensing

in both the high-side and low-side positions. It senses

• Adjustable Soft-Start

the low-side switch voltage drop for providing a

• Tracking and Sequencing with Shutdown and

simple, adjustable current limit.

Soft-Start Pins

The fixed-frequency voltage-mode PWM control

• Switching Frequency from 50 kHz to 1 MHz

architecture is adjustable from 50 kHz to 1 MHz with

one external resistor. This wide range of switching

• TSSOP-14 Package

frequency gives the power supply designer the

flexibility to make better tradeoffs between

APPLICATIONS

component size, cost and efficiency.

• 3.3V Buck Regulation

Features include soft-start, input under-voltage

• Cable Modem, DSL and ADSL

lockout (UVLO) and Power Good (based on both

• Laser Jet and Ink Jet Printers

under-voltage and over-voltage detection). In

addition, the shutdown pin of the IC can be used for

• Low Voltage Power Modules

providing startup delay, and the soft-start pin can be

• DSP, ASIC, Core and I/O

used for implementing precise tracking, for the

purpose of sequencing with respect to an external

rail.

Typical Application

Figure 1. Typical Application Circuit

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2All trademarks are the property of their respective owners.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.
