MSP430F5342, MSP430F5341, MSP430F5340

www.ti.com

SLAS706E –JULY 2011–REVISED AUGUST 2013

MSP430F534x Mixed Signal Microcontroller

Check for Samples: MSP430F5342, MSP430F5341, MSP430F5340

FEATURES

• Low Supply-Voltage Range:

• 16-Bit Timer TA0, Timer_A With Five

3.6 V Down to 1.8 V Capture/Compare Registers

• Ultralow-Power Consumption • 16-Bit Timer TA1, Timer_A With Three

Capture/Compare Registers

– Active Mode (AM):

All System Clocks Active • 16-Bit Timer TA2, Timer_A With Three

290 µA/MHz at 8 MHz, 3 V, Flash Program Capture/Compare Registers

Execution (Typical)

• 16-Bit Timer TB0, Timer_B With Seven

150 µA/MHz at 8 MHz, 3 V, RAM Program

Capture/Compare Shadow Registers

Execution (Typical)

• Two Universal Serial Communication

– Standby Mode (LPM3):

Interfaces (USCI)

Real-Time Clock With Crystal, Watchdog,

– USCI_A0 and USCI_A1 Each Support:

and Supply Supervisor Operational, Full

– Enhanced UART Supports Auto-

RAM Retention, Fast Wake-Up:

Baudrate Detection

1.9 µA at 2.2 V, 2.1 µA at 3 V (Typical)

– IrDA Encoder and Decoder

Low-Power Oscillator (VLO), General-

Purpose Counter, Watchdog, and Supply – Synchronous SPI

Supervisor Operational, Full RAM

– USCI_B0 and USCI_B1 Each Support:

Retention, Fast Wake-Up:

– I

1.4 µA at 3 V (Typical)

– Synchronous SPI

– Off Mode (LPM4):

• 12-Bit Analog-to-Digital Converter (ADC) With

Full RAM Retention, Supply Supervisor

Internal Reference, Sample-and-Hold, and

Operational, Fast Wake-Up:

Autoscan Feature

1.1 µA at 3 V (Typical)

• Comparator

– Shutdown Mode (LPM4.5):

• Hardware Multiplier Supports 32-Bit

0.18 µA at 3 V (Typical)

Operations

• Wake Up From Standby Mode in 3.5 µs (Typ)

• Serial Onboard Programming, No External

• 16-Bit RISC Architecture, Extended Memory,

Programming Voltage Needed

Up to 25-MHz System Clock

• Three-Channel Internal DMA

• Flexible Power Management System

• Basic Timer With Real-Time Clock Feature

– Fully Integrated LDO With Programmable

• Table 1 Summarizes Family Members

Regulated Core Supply Voltage

• For Complete Module Descriptions, See the

– Supply Voltage Supervision, Monitoring,

MSP430x5xx and MSP430x6xx Family User's

and Brownout

Guide (SLAU208)

• Unified Clock System

– FLL Control Loop for Frequency

APPLICATIONS

Stabilization

• Analog Sensor Systems

– Low-Power Low-Frequency Internal Clock

• Digital Sensor Systems

Source (VLO)

• Data Loggers

– Low-Frequency Trimmed Internal Reference

• General-Purpose Applications

Source (REFO)

– 32-kHz Watch Crystals (XT1)

– High-Frequency Crystals up to 32 MHz

(XT2)

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2MSP430, Code Composer Studio are trademarks of Texas Instruments.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.
