MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 D Low Supply-Voltage Range, 1.8 V to 3.6 V D Ultralow-Power Consumption: D D D D D D D D D Active Mode: 250 μA at 1 MHz, 2.2 V Standby Mode: 1.1 μA Off Mode (RAM Retention): 0.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 pin designation, DL package DL PACKAGE (TOP VIEW) TDO/TDI TDI/TCLK TMS TCK RST/NMI DVCC DVSS XIN XOUT AVSS AVCC VREF P6.0/A0+/OA0O P6.1/A0−/OA0FB P6.2/A1+/OA1O P6.3/A1−/OA1FB P6.4/OA0I1 P6.5/OA0I2 P6.6/OA1I1 P6.7/OA1I2 P1.7/A2+ P1.6/A2−/OA0I0 P1.5/TACLK/ACLK/A3+ P1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 47 46 45 44 43 42 41 40 39 38 P2.1/S12/SW1C COM0 P5.2/COM1 P5.3/COM2 P5.4/COM3 TDO/TDI TDI/TCLK TMS TCK RST/NMI DVCC RGZ PACKAGE (TOP VIEW) P2.0/S13/SW0C pin designation, RGZ package P2.2/S11 2 35 P2.3/S10 XOUT 3 34 P2.4/S9 AVSS 4 33 P2.5/S8 AVCC 5 32 P2.6/S7 VREF 6 31 P2.7/S6 P6.0/A0+/OA0O 7 30 S5 P6.1/A0−/OA0FB 8 29 P5.7/S4 P6.2/A1+/OA1O 9 28 P5.6/S3 P6.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 functional block diagram XIN XOUT DVCC DVSS AVCC AVSS P1 P6 P5 P2 8 8 8 8 ACLK Oscillator FLL+ SMCLK MCLK 8 MHz CPU incl.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Terminal Functions TERMINAL NAME DESCRIPTION DL NO. RGZ NO. I/O TDO/TDI 1 43 I/O TDI/TCLK 2 44 I Test data input / test clock input. The device protection fuse is connected to TDI/TCLK. TMS 3 45 I Test mode select. TMS is used as an input port for device programming and test. TCK 4 46 I Test clock. TCK is the clock input port for device programming and test.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Terminal Functions (Continued) TERMINAL NAME DESCRIPTION DL NO. RGZ NO. I/O P2.5/S8 39 33 I/O General-purpose digital I/O / LCD segment output 8 P2.4/S9 40 34 I/O General-purpose digital I/O / LCD segment output 9 P2.3/S10 41 35 I/O General-purpose digital I/O / LCD segment output 10 P2.2/S11 42 36 I/O General-purpose digital I/O / LCD segment output 11 P2.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 short-form description CPU The MSP430 CPU has a 16-bit RISC architecture that is highly transparent to the application. All operations, other than program-flow instructions, are performed as register operations in conjunction with seven addressing modes for source operand and four addressing modes for destination operand.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 operating modes The MSP430 has one active mode and five software selectable low-power modes of operation. An interrupt event can wake up the device from any of the five low-power modes, service the request, and restore back to the low-power mode on return from the interrupt program.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 interrupt vector addresses The interrupt vectors and the power-up starting address are located in the address range 0FFFFh to 0FFE0h. The vector contains the 16-bit address of the appropriate interrupt-handler instruction sequence. Table 3.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 special function registers (SFRs) The MSP430 SFRs are located in the lowest address space and are organized as byte-mode registers. SFRs should be accessed with byte instructions. interrupt enable registers 1 and 2 7 Address 6 0h 5 4 ACCVIE NMIIE OFIE WDTIE rw–0 rw–0 rw–0 rw–0 3 2 1 WDTIE: Watchdog-timer interrupt enable. Inactive if watchdog mode is selected.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 module enable registers 1 and 2 Address 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0 04h Address 05h Legend: rw: rw–0,1: rw–(0,1): Bit Can Be Read and Written Bit Can Be Read and Written. It Is Reset or Set by PUC. Bit Can Be Read and Written. It Is Reset or Set by POR.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 flash memory The flash memory can be programmed via the JTAG port, the bootstrap loader, or in-system by the CPU. The CPU can perform single-byte and single-word writes to the flash memory. Features of the flash memory include: D Flash memory has n segments of main memory and two segments of information memory (A and B) of 128 bytes each. Each segment in main memory is 512 bytes in size.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 peripherals Peripherals are connected to the CPU through data, address, and control buses and can be handled using all instructions. For complete module descriptions, refer to the MSP430x4xx Family User’s Guide, literature number SLAU056.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Timer_A3 Timer_A3 is a 16-bit timer/counter with three capture/compare registers. Timer_A3 can support multiple capture/compares, PWM outputs, and interval timing. Timer_A3 also has extensive interrupt capabilities. Interrupts may be generated from the counter on overflow conditions and from each of the capture/compare registers.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 operational amplifier (OA) The MSP430FG42x0 has two configurable low-current general-purpose operational amplifiers. Each OA input and output terminal is software-selectable and offers a flexible choice of connections for various applications. The OAs primarily support front-end analog signal conditioning prior to analog-to-digital conversion.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 peripheral file map PERIPHERALS WITH WORD ACCESS Watchdog Watchdog timer control WDTCTL 0120h Timer_A3 _ Capture/compare register 2 TACCR2 0176h Capture/compare register 1 TACCR1 0174h Capture/compare register 0 TACCR0 0172h Timer_A register TAR 0170h Capture/compare control 2 TACCTL2 0166h Capture/compare control 1 TACCTL1 0164h Capture/compare control 0 TACCTL0 0162h Timer_A control TACTL 0160
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 peripheral file map (continued) PERIPHERALS WITH BYTE ACCESS (CONTINUED) FLL+ Clock FLL+ Control 1 FLL_CTL1 054h FLL+ Control 0 FLL_CTL0 053h System clock frequency control SCFQCTL 052h System clock frequency integrator SCFI1 051h System clock frequency integrator SCFI0 050h Basic Timer1 BT counter 2 BT counter 1 BT control BTCNT2 BTCNT1 BTCTL 047h 046h 040h Port P6 Port P6 selection P6SEL 037h Port
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 absolute maximum ratings over operating free-air temperature (unless otherwise noted)† Voltage applied at VCC to VSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −0.3 V to 4.1 V Voltage applied to any pin (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −0.3 V to VCC + 0.3 V Diode current at any device terminal . . .
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) supply current into AVCC + DVCC excluding external current PARAMETER TEST CONDITIONS Active mode (see Note 1), f(MCLK) = f(SMCLK) = 1 MHz, f(ACLK) = 32,768 Hz XTS=0, SELM=(0,1) TA = −40°C 40°C to 85°C I(LPM0) Low power mode (LPM0) Low-power (see Note 1 and Note 4) TA = −40°C 40°C to 85°C I(LPM2) Low-power mode (LPM2)
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) Schmitt-trigger inputs − Ports P1, P2, P5, and P6; RST/NMI; JTAG: TCK, TMS, TDI/TCLK, TDO/TDI PARAMETER TEST CONDITIONS VIT+ Positive going input threshold voltage Positive-going VIT− Negative going input threshold voltage Negative-going Vhys Input voltage hysteresis (VIT+ − VIT−) MIN TYP MAX VCC = 2.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) outputs − ports P1, P2, P5, and P6 PARAMETER VOH VOL High level output voltage High-level Low level output voltage Low-level TEST CONDITIONS MIN TYP MAX IOH(max) = −1.5 mA, VCC = 2.2 V, See Note 1 VCC−0.25 VCC IOH(max) = −6 mA, VCC = 2.2 V, See Note 2 VCC−0.6 VCC IOH(max) = −1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) outputs − ports P1, P2, P5, and P6 (continued) TYPICAL LOW-LEVEL OUTPUT CURRENT vs LOW-LEVEL OUTPUT VOLTAGE TYPICAL LOW-LEVEL OUTPUT CURRENT vs LOW-LEVEL OUTPUT VOLTAGE 50 VCC = 2.2 V P1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) wake-up LPM3 PARAMETER TEST CONDITIONS MIN TYP f = 1 MHz td(LPM3) f = 2 MHz Delay time MAX UNIT 6 6 VCC = 2.2 V/3 V f = 3 MHz μs 6 RAM PARAMETER TEST CONDITIONS VRAMh MIN CPU halted (see Note 1) TYP MAX 1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) POR/brownout reset (BOR) (see Note 1) PARAMETER TEST CONDITIONS MIN TYP td(BOR) dVCC/dt ≤ 3 V/s (see Figure 6) VCC(start) V(B_IT−) Vhys(B_IT−) t(reset) UNIT 2000 μs 0.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) typical characteristics (continued) VCC 3V 2 VCC(drop)− V VCC = 3 V Typical Conditions t pw 1.5 1 VCC(drop) 0.5 0 0.001 1 1000 1 ns tpw − Pulse Width − μs 1 ns tpw − Pulse Width − μs Figure 7.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) DCO PARAMETER VCC f(DCOCLK) N(DCO)=01Eh, FN_8=FN_4=FN_3=FN_2=0, D = 2, DCOPLUS= 0, fCrystal = 32.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Sn - Stepsize Ratio between DCO Taps electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) 1.17 ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ ÎÎÎÎÎÎÎÎÎÎÎÎÎ Max 1.11 1.07 1.06 Min 1 20 27 DCO Tap Figure 10.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) crystal oscillator, LFXT1 oscillator (see Notes 1 and 2) PARAMETER CXIN CXOUT Integrated input capacitance (see Note 4) Integrated output capacitance (see Note 4) TEST CONDITIONS MIN 0 OSCCAPx = 1h, VCC = 2.2 V / 3 V 10 OSCCAPx = 2h, VCC = 2.2 V / 3 V 14 OSCCAPx = 3h, VCC = 2.2 V / 3 V 18 OSCCAPx = 0h, VCC = 2.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) SD16_A, power supply and recommended operating conditions PARAMETER AVCC ISD16 fSD16 Analog supply voltage Analog supply current including internal reference Analog front-end input clock frequency TEST CONDITIONS VCC MIN AVCC = DVCC AVSS = DVSS = 0V TYP MAX 2.5 3.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) SD16_A, performance (fSD16 = 30kHz, SD16REFON = 1, SD16BUFx = 01) PARAMETER TEST CONDITIONS VCC MIN SD16GAINx = 1,Signal Amplitude = 500mV SD16OSRx = 256 SINAD Signal-to-noise + distortion ratio SD16GAINx = 1,Signal Amplitude = 500mV SD16OSRx = 512 TYP MAX UNIT 84 fIN = 2.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) SD16_A, temperature sensor PARAMETER TEST CONDITIONS VCC MIN TCSensor Sensor temperature coefficient 1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) 12-bit DAC, supply specifications PARAMETER AVCC Analog supply voltage TEST CONDITIONS VCC AVCC = DVCC, AVSS = DVSS = 0 V Supply current (see Notes 1 and 2) DAC12AMPx = 2, DAC12IR=1, DAC12_xDAT = 0800h, VREF,DAC12 = AVCC DAC12AMPx = 5, DAC12IR = 1, DAC12_xDAT = 0800h, VREF,DAC12 = AVCC Power supply rejecti
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) 12-bit DAC, linearity specifications (see Figure 12) PARAMETER TEST CONDITIONS VCC MIN TYP MAX Resolution 12-bit monotonic INL Integral nonlinearity (see Note 1) VREF,DAC12 = 1.2 V, DAC12AMPx = 7, DAC12IR = 1 2.7 V ±2.0 ±8.0 LSB DNL Differential nonlinearity (see Note 1) VREF,DAC12 = 1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) 12-bit DAC, linearity specifications (continued) TYPICAL INL ERROR vs DIGITAL INPUT DATA INL − Integral Nonlinearity Error − LSB 4 VCC = 2.2 V, VREF = 1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued) 12-bit DAC, output specifications PARAMETER TEST CONDITIONS VCC MIN No load, VREF,DAC12 = AVCC, DAC12_xDAT = 0h, DAC12IR = 1, DAC12AMPx = 7 VO No load, VREF,DAC12 = AVCC, DAC12_xDAT = 0FFFh, DAC12IR = 1, DAC12AMPx = 7 Output voltage range (see Note 1, Figure 15) RLoad = 3 kΩ, VREF,DAC12 = AVCC, DAC12_xDAT
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) 12-bit DAC, reference input specifications PARAMETER TEST CONDITIONS VREF Reference input voltage range Ri(VREF) Reference input resistance NOTES: 1. 2. 3. 4. VCC MIN DAC12IR=0 (see Notes 1 and 2) 2 2V/3V 2.2V/3V DAC12IR=1 (see Notes 3 and 4) DAC12IR=0 TYP MAX AVCC/3 AVCC+0.2 AVCC AVCC+0.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) Conversion 1 Conversion 2 Conversion 3 VOUT 90% 90% 10% 10% tSRLH tSRHL Figure 17.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) operational amplifier OA, supply specifications PARAMETER VCC TEST CONDITIONS Supply voltage VCC MIN — TYP 2.2 Fast Mode ICC Supply S l currentt (see Note 1) Medium Mode 2 2 V/3 V 2.2 Slow Mode PSRR Power supply rejection ratio Non-inverting MAX 2.2 V/3 V UNIT 3.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) operational amplifier OA, dynamic specifications PARAMETER TEST CONDITIONS VCC MIN TYP Fast Mode SR Medium Mode Slew rate 0.8 — Slow Mode UNIT V/μs 0.3 Open-loop voltage gain φm MAX 1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 electrical characteristics over recommended operating free-air temperature (unless otherwise noted) flash memory TEST CONDITIONS PARAMETER VCC(PGM/ VCC MIN TYP MAX UNIT Program and erase supply voltage 2.5 3.6 V fFTG Flash timing generator frequency 257 476 kHz IPGM Supply current from DVCC during program 2.5V/3.6V 3 5 mA IERASE Supply current from DVCC during erase 2.5V/3.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 input/output schematics Port P1 pin schematic: P1.0, P1.1, input/output with Schmitt trigger Pad Logic DV SS DV SS DV SS P1DIR.x 0 Direction 0: Input 1: Output 1 P1OUT.x 0 Module X OUT 1 Bus Keeper P1SEL.x P1.0/TA0 P1.1/TA0/MCLK EN P1IN.x EN Module X IN D P1IE.x P1IRQ.x EN Q Set P1IFG.x P1SEL.x P1IES.x Interrupt Edge Select Note: x = 0,1 Port P1 (P1.0, P1.1) pin functions PIN NAME (P1.X) (P1 X) P1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P1 pin schematic: P1.2, input/output with Schmitt trigger and analog functions INCH=4 Pad Logic 0 AV SS A4− 1 SD16AE.x P1DIR.x 0 Direction 0: Input 1: Output 1 P1OUT.x 0 Module X OUT 1 P1.2/TA1/A4− Bus Keeper P1SEL.x EN P1IN.x EN Module X IN D P1IE.x P1IRQ.x EN Q P1IFG.x Set Interrupt Edge Select P1SEL.x P1IES.x Note: x = 2 Port P1 (P1.2) pin functions (P1 X) PIN NAME (P1.X) P1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P1 pin schematic: P1.3, P1.5, P1.7, input/output with Schmitt trigger and analog functions INCH=y Pad Logic Ay+ SD16AE.x P1DIR.x 0 Direction 0: Input 1: Output 1 P1OUT.x 0 Module X OUT 1 Bus Keeper P1SEL.x P1.3/TA2/A4+ P1.5/TACLK/ACLK/A3+ P1.7/A2+ EN P1IN.x EN Module X IN P1IRQ.x D P1IE.x EN Q P1IFG.x P1SEL.x P1IES.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P1 (P1.3, P1.5, P1.7) pin functions (P1 X) PIN NAME (P1.X) P1.3/TA2/A4+ CONTROL BITS / SIGNALS X 3 FUNCTION P1.3† Input/Output Timer_A3.CCI2A P1.5/TACLK/ACLK/A3+ 5 7 P1SEL.x SD16AE.x 0/1 0 0 0 1 0 Timer_A3.TA2 1 1 0 A4+ (see Note 3) X X 1 P1.5† Input/Output 0/1 0 0 Timer_A3.TACLK/INCLK 0 1 0 ACLK 1 1 0 A3+ (see Note 3) P1.7/A2+ P1DIR.x P1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P1 pin schematic: P1.4, input/output with Schmitt trigger and analog functions INCH=3 Pad Logic 0 AV SS A3− 1 SD16AE.x DAC12OPS P1DIR.x 0 Direction 0: Input 1: Output 1 P1OUT.x 0 DV SS 1 P1.4/A3−/OA1I0/DAC0 Bus Keeper P1SEL.x EN P1IN.x DAC12OPS P1IE.x P1IRQ.x DAC0 EN Q Set P1IFG.x Interrupt Edge Select P1SEL.x P1IES.x + OA1 − Note: x = 4 Port P1 (P1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P1 pin schematic: P1.6, input/output with Schmitt trigger and analog functions INCH=2 Pad Logic 0 AV SS A2− 1 SD16AE.x P1DIR.x 0 Direction 0: Input 1: Output 1 P1OUT.x DV SS 0 1 P1.6/A2−/OA0I0 Bus Keeper P1SEL.x EN P1IN.x P1IE.x EN P1IRQ.x Q P1IFG.x + OA0/1 − Set Interrupt Edge Select P1SEL.x P1IES.x Note: x = 6 Port P1 (P1.6) pin functions (P1 X) PIN NAME (P1.X) P1.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P2 pin schematic: P2.0 to P2.1, input/output with Schmitt trigger, LCD and analog functions Pad Logic LCDS12 Segment Sy P2DIR.x 0 Direction 0: Input 1: Output 1 P2OUT.x DV SS 0 1 P2.0/S13/SW0C P2.1/S12/SW1C Bus Keeper P2SEL.x EN P2IN.x P2IE.x P2IRQ.x SWCTL.SWCLT2 (SW0C) SWCTL.SWCLT6 (SW1C) EN Q Set P2IFG.x AV SS Interrupt Edge Select P2SEL.x P2IES.x Note: x = 0,1 y = 13,12 Port P2 (P2.0, P2.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P2 pin schematic: P2.2 to P2.7, input/output with Schmitt trigger, LCD and analog functions Pad Logic LCDS4/8/12 Segment Sy DV SS P2DIR.x 0 Direction 0: Input 1: Output 1 P2OUT.x DV SS 0 1 Bus Keeper P2SEL.x EN P2IN.x P2IE.x P2IRQ.x EN Q P2IFG.x P2SEL.x P2IES.x Set Interrupt Edge Select Note: x = 2 to 7 y = 11 to 6 48 POST OFFICE BOX 655303 • DALLAS, TEXAS 75265 P2.2/S11 P2.3/S10 P2.4/S9 P2.5/S8 P2.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P2 (P2.0 to P2.7) pin functions (P2 X) PIN NAME (P2.X) P2.2/S11 CONTROL BITS / SIGNALS X 2 FUNCTION P2.2† Input/Output N/A P2.3/S10 3 4 5 6 7 1 0 1 1 0 X 1 P2.3† Input/Output 0/1 0 0 N/A 0 1 0 DVSS 1 1 0 P2.4† Input/Output X X 1 0/1 0 0 0 1 0 DVSS 1 1 0 S9 X X 1 0/1 0 0 N/A 0 1 0 DVSS 1 1 0 P2.5† Input/Output P2.6† Input/Output N/A P2.7/S6 0 0 X S8 P2.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P5 pin schematic: P5.0, P5.1, P5.5 to P5.7, input/output with Schmitt trigger and LCD functions Pad Logic LCDS0/4 Segment Sy DV SS P5DIR.x 0 1 P5OUT.x DV SS P5SEL.x Direction 0: Input 1: Output 0 1 Bus Keeper EN P5IN.x Note: x = 0,1,5,6,7 y = 1,0,2,3,4 50 POST OFFICE BOX 655303 • DALLAS, TEXAS 75265 P5.0/S1 P5.1/S0 P5.5/S2 P5.6/S3 P5.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P5 (P5.0, P5.1, P5.5, P5.6) pin functions (P5 X) PIN NAME (P5.X) P5.0/S1 CONTROL BITS / SIGNALS X 0 FUNCTION P5.0† Input/Output N/A P5.1/S0 1 5 6 LCDS0 0 0 0 1 0 1 1 0 S1 X X 1 P5.1† Input/Output 0/1 0 0 N/A 0 1 0 DVSS 1 1 0 P5.5† Input/Output N/A P5.6/S3 P5SEL.x 0/1 DVSS S0 P5.5/S2 P5DIR.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P5 pin schematic: P5.2 to P5.4, input/output with Schmitt trigger and LCD functions Pad Logic LCD Signal DV SS P5DIR.x 0 Direction 0: Input 1: Output 1 P5OUT.x DV SS 0 1 Bus Keeper P5SEL.x P5.2/COM1 P5.3/COM2 P5.4/COM3 EN P5IN.x Note: x = 2 to 4 Port P5 (P5.2 to P5.4) pin functions (P5 X) PIN NAME (P5.X) CONTROL BITS / SIGNALS X P5.2/COM1 2 P5.3/COM2 3 FUNCTION P5.2† Input/Output COM1 P5.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P6 pin schematic: P6.0, P6.2, input/output with Schmitt trigger and analog functions INCH=0/1 # Pad Logic Ay+ # P6DIR.x 0 Direction 0: Input 1: Output 1 P6OUT.x DV SS 0 1 Bus Keeper P6SEL.x P6.0/A0+/OA0O P6.2/A1+/OA1O EN P6IN.x Note: x = 0,2 y = 0,1 #Signal from or to SD16 + OA0/1 − Port P6 (P6.0, P6.2) pin functions PIN NAME (P6.X) (P6 X) P6.0/A0+/OA0O CONTROL BITS / SIGNALS X 0 FUNCTION P6.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P6 pin schematic: P6.1, P6.3, input/output with Schmitt trigger and analog functions INCH=0/1 # Pad Logic Ay−# P6DIR.x 0 Direction 0: Input 1: Output 1 P6OUT.x DV SS 0 1 Bus Keeper P6SEL.x P6.1/A0−/OA0FB P6.3/A1−/OA1FB EN P6IN.x Note: x = 1,3 y = 0,1 #Signal from or to SD16 + OA0/1 − Port P6 (P6.1, P6.3) pin functions PIN NAME (P6.X) (P6 X) P6.1/A0−/OA0FB CONTROL BITS / SIGNALS X 1 FUNCTION P6.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Port P6 pin schematic: P6.4 to P6.7, input/output with Schmitt trigger and analog functions P6DIR.x Pad Logic 0 Direction 0: Input 1: Output 1 P6OUT.x DV SS 0 1 Bus Keeper P6SEL.x P6.4/OA0I1 P6.5/OA0I2 P6.6/OA1I1 P6.7/OA1I2 EN P6IN.x + OA0/1 − Note: x = 4 to 7 Port P6 (P6.4 to P6.7) pin functions PIN NAME (P6.X) (P6 X) CONTROL BITS / SIGNALS X P6.4/OA0I1 4 P6.5/OA0I2 5 P6.6/OA1I1 P6.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 JTAG pins TMS, TCK, TDI/TCLK, TDO/TDI, input/output with Schmitt trigger or output TDO Controlled by JTAG Controlled by JTAG TDO/TDI JTAG Controlled by JTAG DVCC TDI Burn and Test Fuse TDI/TCLK Test and Emulation DVCC TMS Module TMS DVCC TCK TCK RST/NMI Tau ~ 50 ns Brownout TCK 56 POST OFFICE BOX 655303 • DALLAS, TEXAS 75265 G D U S G D U S
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 JTAG fuse check mode MSP430 devices that have the fuse on the TDI/TCLK terminal have a fuse check mode that tests the continuity of the fuse the first time the JTAG port is accessed after a power-on reset (POR). When activated, a fuse check current (I(TF) ) of 1 mA at 3 V can flow from the TDI/TCLK pin to ground if the fuse is not burned.
MSP430FG42x0 MIXED SIGNAL MICROCONTROLLER SLAS556A − JULY 2007 − REVISED AUGUST 2007 Data Sheet Revision History Literature Number Summary SLAS556 Product Preview data sheet release SLAS556A Production Data data sheet release NOTE: Page and figure numbers refer to the respective document revision.
PACKAGE OPTION ADDENDUM www.ti.
PACKAGE OPTION ADDENDUM www.ti.com 11-Apr-2013 Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements for all 6 substances, including the requirement that lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes.
PACKAGE MATERIALS INFORMATION www.ti.com 14-Jul-2012 TAPE AND REEL INFORMATION *All dimensions are nominal Device Package Package Pins Type Drawing SPQ Reel Reel A0 Diameter Width (mm) (mm) W1 (mm) B0 (mm) K0 (mm) P1 (mm) W Pin1 (mm) Quadrant MSP430FG4250IDLR SSOP DL 48 1000 330.0 32.4 11.35 16.2 3.1 16.0 32.0 Q1 MSP430FG4260IDLR SSOP DL 48 1000 330.0 32.4 11.35 16.2 3.1 16.0 32.0 Q1 MSP430FG4270IDLR SSOP DL 48 1000 330.0 32.4 11.35 16.2 3.1 16.0 32.
PACKAGE MATERIALS INFORMATION www.ti.com 14-Jul-2012 *All dimensions are nominal Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm) MSP430FG4250IDLR SSOP DL 48 1000 367.0 367.0 55.0 MSP430FG4260IDLR SSOP DL 48 1000 367.0 367.0 55.0 MSP430FG4270IDLR SSOP DL 48 1000 367.0 367.0 55.
