OPA1602

OPA1604

www.ti.com

SBOS474B –APRIL 2011–REVISED NOVEMBER 2011

™ High-Performance, Bipolar-Input

AUDIO OPERATIONAL AMPLIFIERS

Check for Samples: OPA1602, OPA1604

FEATURES

DESCRIPTION

The OPA1602 and OPA1604 bipolar-input

234

• SUPERIOR SOUND QUALITY

operational amplifiers achieve very low 2.5nV/√Hz

• ULTRALOW NOISE: 2.5nV/√Hz at 1kHz

noise density with an ultralow distortion of 0.00003%

• ULTRALOW DISTORTION: 0.00003% at 1kHz

at 1kHz. The OPA1602 and OPA1604 series of op

amps offer rail-to-rail output swing to within 600mV

• HIGH SLEW RATE: 20V/μs

with 2kΩ load, which increases headroom and

• WIDE BANDWIDTH: 35MHz (G = +1)

maximizes dynamic range. These devices also have

• HIGH OPEN-LOOP GAIN: 120dB

a high output drive capability of ±30mA.

• UNITY GAIN STABLE

These devices operate over a very wide supply range

• LOW QUIESCENT CURRENT:

of ±2.25V to ±18V, on only 2.6mA of supply current

2.6mA PER CHANNEL

per channel. The OPA1602 and OPA1604 are

unity-gain stable and provide excellent dynamic

• RAIL-TO-RAIL OUTPUT

behavior over a wide range of load conditions.

• WIDE SUPPLY RANGE: ±2.25V to ±18V

These devices also feature completely independent

• DUAL AND QUAD VERSIONS AVAILABLE

circuitry for lowest crosstalk and freedom from

interactions between channels, even when overdriven

APPLICATIONS

or overloaded.

• PROFESSIONAL AUDIO EQUIPMENT

The OPA1602 and OPA1604 are specified

• BROADCAST STUDIO EQUIPMENT

from –40°C to +85°C. SoundPlus™

• ANALOG AND DIGITAL MIXERS

• HIGH-END A/V RECEIVERS

• HIGH-END BLU-RAY™ PLAYERS

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas

Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2SoundPlus is a trademark of Texas Instruments Incorporated.

3BLU-RAY is a trademark of Blu-ray Disc Association.

4All other trademarks are the property of their respective owners.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

Summary of content (29 pages)

PAGE 1
OPA1602 OPA1604 Burr-Brown Audio SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com ™ High-Performance, Bipolar-Input AUDIO OPERATIONAL AMPLIFIERS Check for Samples: OPA1602, OPA1604 FEATURES DESCRIPTION • • • • • • • • The OPA1602 and OPA1604 bipolar-input operational amplifiers achieve very low 2.5nV/√Hz noise density with an ultralow distortion of 0.00003% at 1kHz.
PAGE 2
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage. ESD damage can range from subtle performance degradation to complete device failure.
PAGE 3
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com ELECTRICAL CHARACTERISTICS: VS = ±2.25V to ±18V At TA = +25°C and RL = 2kΩ, unless otherwise noted. VCM = VOUT = midsupply, unless otherwise noted. OPA1602, OPA1604 PARAMETER CONDITIONS MIN TYP MAX UNIT AUDIO PERFORMANCE Total Harmonic Distortion + Noise Intermodulation Distortion THD+N IMD G = +1, f = 1kHz, VO = 3VRMS 0.
PAGE 4
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com ELECTRICAL CHARACTERISTICS: VS = ±2.25V to ±18V (continued) At TA = +25°C and RL = 2kΩ, unless otherwise noted. VCM = VOUT = midsupply, unless otherwise noted. OPA1602, OPA1604 PARAMETER CONDITIONS MIN TYP MAX UNIT ±18 V POWER SUPPLY Specified Voltage ±2.25 VS Quiescent Current (3) xx Dual, per channel Quad, per channel IQ IOUT = 0A 2.6 3.2 mA IQ IOUT = 0A 2.8 3.
PAGE 5
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com TYPICAL CHARACTERISTICS At TA = +25°C, VS = ±15V, and RL = 2kΩ, unless otherwise noted. INPUT VOLTAGE NOISE DENSITY AND INPUT CURRENT NOISE DENSITY vs FREQUENCY 0.1Hz TO 10Hz NOISE 10 50nV/div Voltage Noise Density (nV/?Hz) Input Bias Current Noise (pA/?Hz) 100 Voltage Noise Density Current Noise Density 1 0.1 1 10 100 1k 10k Time (1s/div) 100k Frequency (Hz) Figure 1. Figure 2.
PAGE 6
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com TYPICAL CHARACTERISTICS (continued) At TA = +25°C, VS = ±15V, and RL = 2kΩ, unless otherwise noted. THD+N RATIO vs FREQUENCY THD+N RATIO vs FREQUENCY 0.00001 -120 RL = 600W VOUT = 3VRMS BW = 80kHz 10 RL = 2kW Total Harmonic Distortion + Noise (%) Total Harmonic Distortion + Noise (%) 0.0001 G = -1, RL = 2kW G = +10, RL = 600W G = +10, RL = 2kW 0.01 -140 100 1k RSOURCE OPA1602 -15V 0.
PAGE 7
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com TYPICAL CHARACTERISTICS (continued) At TA = +25°C, VS = ±15V, and RL = 2kΩ, unless otherwise noted.
PAGE 8
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com TYPICAL CHARACTERISTICS (continued) At TA = +25°C, VS = ±15V, and RL = 2kΩ, unless otherwise noted.
PAGE 9
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com TYPICAL CHARACTERISTICS (continued) At TA = +25°C, VS = ±15V, and RL = 2kΩ, unless otherwise noted. QUIESCENT CURRENT vs TEMPERATURE QUIESCENT CURRENT vs SUPPLY VOLTAGE 4 3 OPA1604 2.9 3.5 2.8 2.7 IQ (mA) IQ (mA) OPA1604 3 2.5 2.6 2.5 OPA1602 2.4 2.3 OPA1602 2 2.2 2.1 <−−−−−− Specified Temperature Range −−−−−−> 1.
PAGE 10
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com APPLICATION INFORMATION applications do not require equal positive and negative output voltage swing. With the OPA160x series, power-supply voltages do not need to be equal. For example, the positive supply could be set to +25V with the negative supply at –5V. The OPA1602 and OPA1604 are unity-gain stable, precision dual and quad op amps with very low noise.
PAGE 11
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com The input terminals of the OPA1602 and OPA1604 are protected from excessive differential voltage with back-to-back diodes, as Figure 32 illustrates. In most circuit applications, the input protection circuitry has no consequence. However, in low-gain or G = +1 circuits, fast ramping input signals can forward bias these diodes because the output of the amplifier cannot respond rapidly enough to the input ramp.
PAGE 12
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 A) Noise in Noninverting Gain Configuration www.ti.
PAGE 13
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com TOTAL HARMONIC DISTORTION MEASUREMENTS The OPA160x series op amps have excellent distortion characteristics. THD + noise is below 0.00008% (G = +1, VO = 3VRMS, BW = 80kHz) throughout the audio frequency range, 20Hz to 20kHz, with a 2kΩ load (see Figure 7 for characteristic performance). The distortion produced by the OPA160x series op amps is below the measurement limit of many commercially available distortion analyzers.
PAGE 14
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 POWER DISSIPATION The OPA1602 and OPA1604 series op amps are capable of driving 2kΩ loads with a power-supply voltage up to ±18V and full operating temperature range. Internal power dissipation increases when operating at high supply voltages. Copper leadframe construction used in the OPA160x series op amps improves heat dissipation compared to conventional materials. Circuit board layout can also help minimize junction temperature rise.
PAGE 15
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com If there is an uncertainty about the ability of the supply to absorb this current, external zener diodes may be added to the supply pins as shown in Figure 36. The zener voltage must be selected such that the diode does not turn on during normal operation. However, its zener voltage should be low enough so that the zener diode conducts if the supply pin begins to rise above the safe operating supply voltage level.
PAGE 16
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com APPLICATION CIRCUIT An additional application idea is shown in Figure 37. 820W 2200pF +VA (+15V) 0.1mF 330W IOUTL+ OPA160x 2700pF -VA (-15V) 680W 620W Audio DAC with Differential Current Outputs 0.1mF +VA (+15V) 0.1mF 100W 820W OPA160x 8200pF 2200pF +VA (+15V) L Ch Output -VA (-15V) 0.1mF 0.1mF 680W 620W IOUTLOPA160x 330W 2700pF -VA (-15V) 0.1mF Figure 37.
PAGE 17
OPA1602 OPA1604 SBOS474B – APRIL 2011 – REVISED NOVEMBER 2011 www.ti.com REVISION HISTORY NOTE: Page numbers for previous revisions may differ from page numbers in the current version. Changes from Revision A (April, 2011) to Revision B Page • Revised minimum and typical Common-mode rejection ratio specifications ........................................................................ 3 • Added footnote (2) to Electrical Characteristics table ..........................................................
PAGE 18
PACKAGE OPTION ADDENDUM www.ti.
PAGE 19
PACKAGE OPTION ADDENDUM www.ti.com 11-Apr-2013 (4) Multiple Top-Side Markings will be inside parentheses. Only one Top-Side Marking contained in parentheses and separated by a "~" will appear on a device. If a line is indented then it is a continuation of the previous line and the two combined represent the entire Top-Side Marking for that device. Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided.
PAGE 20
PACKAGE MATERIALS INFORMATION www.ti.com 26-Jan-2013 TAPE AND REEL INFORMATION *All dimensions are nominal Device Package Package Pins Type Drawing OPA1602AIDGKR VSSOP DGK OPA1602AIDR SOIC OPA1604AIDR SOIC OPA1604AIPWR TSSOP SPQ Reel Reel A0 Diameter Width (mm) (mm) W1 (mm) B0 (mm) K0 (mm) P1 (mm) W Pin1 (mm) Quadrant 8 2500 330.0 12.4 5.3 3.4 1.4 8.0 12.0 Q1 D 8 2500 330.0 12.4 6.4 5.2 2.1 8.0 12.0 Q1 D 14 2500 330.0 16.4 6.5 9.0 2.1 8.0 16.
PAGE 21
PACKAGE MATERIALS INFORMATION www.ti.com 26-Jan-2013 *All dimensions are nominal Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm) OPA1602AIDGKR VSSOP DGK 8 2500 358.0 335.0 35.0 OPA1602AIDR SOIC D 8 2500 367.0 367.0 35.0 OPA1604AIDR SOIC D 14 2500 367.0 367.0 38.0 OPA1604AIPWR TSSOP PW 14 2000 367.0 367.0 35.
PAGE 22
PAGE 23
PAGE 24
PAGE 25
PAGE 26
PAGE 27
PAGE 28
PAGE 29
