Names of the Main Unit Parts
STANDBY
STATUS
STANDBY
AUTO
SOURCE
Adjuster button [E-27]
(Also on opposite side)
Focus ring [E-27]
Lens
Exhaust vents
Adjusters [E-27]
Lamp cover [E-65]
Ventilation slots
Focus ring [E-27]
Lens cap
Remove before use. Attach
the lens cap after use to
protect the lens.
Remote control
sensor [E-13]
Lens
Zoom ring [E-26]
Applicable Projector: U5-232/U5-132
Applicable Projector: U5-112
Ventilation slots
Zoom ring [E-26]
Lens
Focus ring [E-27]
Applicable Projector: U5-111
Exhaust
vents
Lens cap
Exhaust
vents
Lens cap
