WIDE OUTPUT ADJUST, POWER MODULE w/ TURBOTRANS™

FEATURES

APPLICATIONS

DESCRIPTION

PTH05T210W

www.ti.com

...................................................................................................................................................... SLTS263I – AUGUST 2007 – REVISED MARCH 2009

30-A, 5-V INPUT, NON-ISOLATED,

• Up to 30-A Output Current • TurboTrans™ Technology

• 4.5-V to 5.5-V Input Voltage • Designed to meet Ultra-Fast Transient

Requirements up to 300 A/ µ s

• Wide-Output Voltage Adjust (0.7 V to 3.6 V)

• Auto-Track™ Sequencing

• Efficiencies up to 96%

• Multi-Phase, Switch-Mode Topology

• ± 1.5% Total Output Voltage Variation

• Safety Agency Approvals:

• On/Off Inhibit

– UL/IEC/CSA-22.2 60950-1

• Differential Output Voltage Remote Sense

• Adjustable Undervoltage Lockout

• Output Overcurrent Protection

• Complex Multi-Voltage Systems

(Nonlatching, Auto-Reset)

• Microprocessors

• Operating Temperature: – 40 ° C to 85 ° C

• Bus Drivers

• POLA™ Compatible

The PTH05T210W is a high-performance 30-A rated, non-isolated power module which utilizes a multi-phase,

switch-mode topology. This module represents the 2nd generation of the PTH series power modules which

includes a reduced footprint and improved features.

Operating from an input voltage range of 4.5 V to 5.5 V, the PTH05T210W requires a single resistor to set the

output voltage to any value over the range, 0.7 V to 3.6 V. The module uses double-sided surface mount

construction to provide a low profile and compact footprint. Package options include both through-hole and

surface mount configurations that are lead (Pb) – free and RoHS compatible.

A new feature included in this 2nd generation of PTH modules is TurboTrans™ technology (patent pending).

TurboTrans allows the transient response of the regulator to be optimized externally, resulting in a reduction of

output voltage deviation following a load transient and a reduction in required output capacitance. This feature

also offers enhanced stability when used with ultra-low ESR output capacitors.

The PTH05T210W incorporates a comprehensive list of standard features. They include on/off inhibit, a

differential remote output voltage sense which ensures tight load regulation, and an output overcurrent and

overtemperature shutdown to protect against load faults. A programmable undervoltage lockout allows the

turn-on voltage threshold to be customized. AutoTrack™ sequencing is a feature which simplifies the

simultaneous power-up and power-down of multiple modules in a power system by allowing the outputs to track

a common voltage.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas

Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2 POLA, TurboTrans, Auto-Track, AutoTrack, TMS320 are trademarks of Texas Instruments.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.
