FEATURES DESCRIPTION
APPLICATIONS
C
IN
2.2 Fm
C
PUMP
0.22 Fm
3.3Vto
4.2V
C
OUT
2.2 Fm
R
LEDGND
Enable
REG71050
REG710-5
LED LED
R R
REG710
www.ti.com
........................................................................................................................................... SBAS221G – DECEMBER 2001 – REVISED JANUARY 2009
60mA, 5.0V, Buck/Boost Charge Pump
in ThinSOT-23 and ThinQFN
2
• Wide Input Range: 1.8V to 5.5V
The REG710 is a switched capacitor voltage
converter that produces a regulated, low-ripple output
• Automatic Step-Up/Step-Down Operation
voltage from an unregulated input voltage. A wide
• Low Input Current Ripple
input supply voltage of 1.8V to 5.5V makes the
• Low Output Voltage Ripple
REG710 ideal for a variety of battery sources, such
• Minimum Number of External as single-cell Li-Ion, or two- and three-cell nickel- or
alkaline-based chemistries.
Components — No Inductors
• 1MHz Internal Oscillator Allows Small
The input voltage may vary above and below the
Capacitors
output voltage and the output remains in regulation. It
works equally well for step-up or step-down
• Shutdown Mode
applications without the need for an inductor,
• Thermal and Current Limit Protection
providing low EMI dc/dc conversion. The high
• Six Output Voltages Available:
switching frequency allows the use of small
surface-mount capacitors, saving board space and
– 5.5V, 5.0V, 3.3V, 3.0V, 2.7V, 2.5V
reducing cost. The REG710 is thermally protected
• Small Packages:
and current limited, protecting the load and the
– SOT23-6
regulator during fault conditions. Typical ground pin
current (quiescent current) is 65 µ A with no load, and
– TSOT23-6 (REG71055 and REG71050 Only)
less than 1 µ A in shutdown mode.
– TQFN-6 (2 × 2 × 0.8mm; REG71050 Only)
• Evaluation Modules Available:
– REG710EVM-33 , REG710EVM-5
• Smart Card Readers
• SIM Card Supplies
• Cellular Phones
• Portable Communication Devices
• Personal Digital Assistants
• Notebook and Palm-Top Computers
• Modems
• Electronic Games
REG710 Used in White LED Backlight Application
• Handheld Meters
• PCMCIA Cards
• Card Buses
• White LED Drivers
• LCD Displays
• Battery Backup Supplies
