Seemechanicaldrawingsfordimensions.
DCTPACKAGE
(TOP VIEW)
DCUPACKAGE
(TOP VIEW)
YZP PACKAGE
(BOTTOMVIEW)
1
V
CC
8
1A
2
7
1B 1Y
3 6
2Y
2B
4
5
GND
2A
3 6
2B
2Y
8
1
V
CC
1A
5
GND
4
2A
2
7
1Y1B
GND
5
4
2A
3
6
2B
2Y
2
7
1Y
1B
8
V
CC
1
1A
SN74LVC2G02
www.ti.com
SCES194M –APRIL 1999–REVISED NOVEMBER 2013
Dual 2-Input Positive-NOR Gate
Check for Samples: SN74LVC2G02
1
FEATURES
DESCRIPTION
This dual 2-input positive-NOR gate is designed for
2
• Available in the Texas Instruments NanoFree™
1.65-V to 5.5-V V
CC
operation.
Package
The SN74LVC2G02 performs the Boolean function Y
• Supports 5-V V
CC
Operation
= A + B or Y = A • B in positive logic.
• Inputs Accept Voltages to 5.5 V
NanoFree™ package technology is a major
• Max t
pd
of 4.9 ns at 3.3 V
breakthrough in IC packaging concepts, using the die
• Low Power Consumption, 10-μA Max I
CC
as the package.
• ±24-mA Output Drive at 3.3 V
This device is fully specified for partial-power-down
• Typical V
OLP
(Output Ground Bounce)
applications using I
off
. The I
off
circuitry disables the
<0.8 V at V
CC
= 3.3 V, T
A
= 25°C
outputs, preventing damaging current backflow
• Typical V
OHV
(Output V
OH
Undershoot)
through the device when it is powered down.
>2 V at V
CC
= 3.3 V, T
A
= 25°C
• I
off
Supports Partial-Power-Down Mode
Operation
• Latch-Up Performance Exceeds 100 mA Per
JESD 78, Class II
• ESD Protection Exceeds JESD 22
– 2000-V Human-Body Model (A114-A)
– 1000-V Charged-Device Model (C101)
