Seemechanicaldrawingsfordimensions.
DCTPACKAGE
(TOP VIEW)
DCUPACKAGE
(TOP VIEW)
YZP PACKAGE
(BOTTOMVIEW)
1
V
CC
8
1A
2
7
3Y 1Y
3 6
2A
3A
4
5
GND
2Y
3 6
3A2A
8
1
V
CC
1A
5
GND
4
2Y
2
7
1Y3Y
GND
5
4
2Y
3
6
3A2A
2
7
1Y3Y
8
V
CC
1
1A
SN74LVC3G14
www.ti.com
SCES367J –AUGUST 2001–REVISED NOVEMBER 2013
Triple Schmitt-Trigger Inverter
Check for Samples: SN74LVC3G14
1
FEATURES
DESCRIPTION
This triple Schmitt-trigger inverter is designed for
2
• Available in the Texas Instruments NanoFree™
1.65-V to 5.5-V V
CC
operation.
Package
The SN74LVC3G14 contains three inverters and
• Supports 5-V V
CC
Operation
performs the Boolean function Y = A. The device
• Inputs Accept Voltages to 5.5 V
functions as three independent inverters but, because
• Max t
pd
of 5.4 ns at 3.3 V
of Schmitt action, it may have different input threshold
levels for positive-going (V
T+
) and negative-going
• Low Power Consumption, 10-μA Max I
CC
(V
T–
) signals.
• ±24-mA Output Drive at 3.3 V
NanoFree™ package technology is a major
• Typical V
OLP
(Output Ground Bounce) <0.8 V at
breakthrough in IC packaging concepts, using the die
V
CC
= 3.3 V, T
A
= 25°C
as the package.
• Typical V
OHV
(Output V
OH
Undershoot) >2 V at
This device is fully specified for partial-power-down
V
CC
= 3.3 V, T
A
= 25°C
applications using I
off
. The I
off
circuitry disables the
• I
off
Feature Supports Live Insertion, Partial-
outputs, preventing damaging current backflow
Power-Down Mode and Back Drive Protection
through the device when it is powered down.
• Latch-Up Performance Exceeds 100 mA Per
JESD 78, Class II
• ESD Protection Exceeds JESD 22
– 2000-V Human-Body Model (A114-A)
– 200-V Machine Model (A115-A)
– 1000-V Charged-Device Model (C101)
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2NanoFree is a trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Copyright © 2001–2013, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
