Instruction Set Summary

7-5

Assembly Language Instructions

Table 7–1. Accumulator, Arithmetic, and Logic Instructions (Continued)

Mnemonic OpcodeCyclesWordsDescription

AND

AND ACC with data value, direct or indirect 1 1 0110 1110 IAAA AAAA

AND with ACC with shift of 0 to 15, long immediate 2 2 1011 1111 1011 SHFT

+ 1 word

AND with ACC with shift of 16, long immediate 2 2 1011 1110 1000 0001

+ 1 word

CMPL Complement ACC 1 1 1011 1110 0000 0001

LACC Load ACC with shift of 0 to 15, direct or indirect 1 1 0001 SHFT IAAA AAAA

Load ACC with shift of 0 to 15, long immediate 2 2 1011 1111 1000 SHFT

+ 1 word

Load ACC with shift of 16, direct or indirect 1 1 0110 1010 IAAA AAAA

LACL Load low word of ACC, direct or indirect 1 1 0110 1001 IAAA AAAA

Load low word of ACC, short immediate 1 1 1011 1001 IIII IIII

LACT Load ACC with shift (0 to 15) specified by TREG,

direct or indirect

1 1 0110 1011 IAAA AAAA

NEG Negate ACC 1 1 1011 1110 0000 0010

NORM Normalize the contents of ACC, indirect 1 1 1010 0000 IAAA AAAA

OR OR ACC with data value, direct or indirect 1 1 0110 1101 IAAA AAAA

OR with ACC with shift of 0 to 15, long immediate 2 2 1011 1111 1100 SHFT

+ 1 word

OR with ACC with shift of 16, long immediate 2 2 1011 1110 1000 0010

+ 1 word

ROL Rotate ACC left 1 1 1011 1110 0000 1100

ROR Rotate ACC right 1 1 1011 1110 0000 1101

SACH Store high ACC with shift of 0 to 7,

direct or indirect

1 1 1001 1SHF IAAA AAAA

SACL Store low ACC with shift of 0 to 7,

direct or indirect

1 1 1001 0SHF IAAA AAAA

SFL Shift ACC left 1 1 1011 1110 0000 1001

SFR

Shift ACC right 1 1 1011 1110 0000 1010
