BLPD

Block Move From Program Memory to Data Memory

7-54

Syntax General syntax: BLPD

source

destination

BLPD #

pma

dma

Direct with long immediate

source

BLPD #

pma

ind

] Indirect with long immediate

source

Operands pma: 16-bit program-memory address

dma: 7 LSBs of the data-memory address

n: Value from 0 to 7 designating the next auxiliary register

ind: Select one of the following seven options:

* *+ *– *0+ *0– *BR0+ *BR0–

BLPD

#pma, dma

1514131211109876543210

01001010 dma

pma

BLPD

#pma, ind

[

]

1514131211109876543210

01001011 ARU N NAR

pma

Note: ARU, N, and NAR are defined in Section 6.3,

Indirect Addressing Mode

(page 6-9).

Execution Increment PC, then ...

(PC) → MSTACK

pma → PC

(source) → destination

For indirect, modify (current AR) and (ARP) as specified

(PC) + 1 → PC

While (repeat counter) ≠ 0:

(source) → destination

For indirect, modify (current AR) and (ARP) as specified

(PC) + 1 → PC

(repeat counter) –1 → repeat counter

(MSTACK) → PC

Status Bits None

Opcode
