OUT

Output Data to Port

7-132

Syntax OUT

dma

Direct addressing

OUT

ind

[, AR

] Indirect addressing

Operands dma: 7 LSBs of the data-memory address

PA: 16-bit I/O address

n: Value from 0 to 7 designating the next auxiliary register

ind: Select one of the following seven options:

* *+ *– *0+ *0– *BR0+ *BR0–

OUT

dma

1514131211109876543210

00011000 dma

OUT

ind

]

1514131211109876543210

00011001 ARU N NAR

Note: ARU, N, and NAR are defined in Section 6.3,

Indirect Addressing Mode

(page 6-9).

Execution Increment PC, then ...

PA → address bus A15–A0

(data-memory address) → data bus D15–D0

(data-memory address) → PA

Status Bits None

Description The OUT instruction writes a 16-bit value from a data-memory location to the

specified I/O location. The IS

line goes low to indicate an I/O access. The

STRB

, R/W, and READY timings are the same as for an external data-memory

write.

RPT can be used with the OUT instruction to write consecutive words from

data memory to I/O space.

Words 2
