RPT
Repeat Next Instruction
7-146
Syntax RPT
dma
 Direct addressing
RPT
ind
 [, AR
n
] Indirect addressing
RPT #
k
Short immediate
Operands dma: 7 LSBs of the data-memory address
n: Value from 0 to 7 designating the next auxiliary register
k: 8-bit short immediate value
ind: Select one of the following seven options:
* *+ *– *0+ *0– *BR0+ *BR0–
RPT
dma
1514131211109876543210
0
00010110 dma
RPT
ind
 [, AR
n
]
1514131211109876543210
0
00010111 ARU N NAR
Note: ARU, N, and NAR are defined in Section 6.3,
Indirect Addressing Mode
 (page 6-9).
RPT #
k
1514131211109876543210
1
0111011 k
Execution Increment PC, then ...
Event Addressing mode
(data-memory address) → RPTC Direct or indirect
k → RPTC Short immediate
Status Bits None
Description The repeat counter (RPTC) is loaded with the content of the addressed data-
memory location if direct or indirect addressing is used; it is loaded with an 8-bit
immediate value if short immediate addressing is used. The instruction follow-
ing the RPT is repeated
n
 times, where
n
 is the initial value of the RPTC plus
1. Since the RPTC cannot be saved during a context switch, repeat loops are
regarded as multicycle instructions and are not interruptible. The RPTC is
cleared to 0 on a device reset.
RPT is especially useful for block moves, multiply/accumulates, and normal-
ization. The repeat instruction itself is not repeatable.
Words 1
Opcode
