SFR

Shift Accumulator Right

7-158

Syntax SFR

Operands None

Opcode

0123456789101112131415

0101000001111101

Execution Increment PC, then ...

If SXM = 0

Then 0 → ACC(31).

If SXM = 1

Then (ACC(31)) → ACC(31)

(ACC(31:1)) → ACC(30:0)

(ACC(0)) → C

Status Bits

Affected by Affects

SXM C

Description The SFR instruction shifts the accumulator right one bit.

If SXM = 1, the instruction produces an arithmetic right shift. The sign bit

(MSB) is unchanged and is also copied into bit 30. Bit 0 is shifted into the

carry bit (C).

If SXM = 0, the instruction produces a logic right shift. All of the accumula-

tor bits are shifted right by one bit. The least significant bit is shifted into

the carry bit, and the most significant bit is filled with a 0.

Words 1

Cycles for a Single SFR Instruction

ROM

DARAM SARAM External

1 1 1 1+p

Cycles for a Repeat (RPT) Execution of an SFR Instruction

ROM

DARAM SARAM External

n n n n+p

Cycles
