Subtract From Accumulator With Shift Specified by TREG

SUBT

7-185

Assembly Language Instructions

Cycles for a Single SUBT Instruction

Program

Operand ROM DARAM SARAM External

DARAM 1 1 1 1+p

SARAM 1 1 1, 2

†

1+p

External 1+d 1+d 1+d 2+d+p

†

If the operand and the code are in the same SARAM block.

Cycles for a Repeat (RPT) Execution of an SUBT Instruction

Program

Operand

ROM

DARAM SARAM External

DARAM n n n n+p

SARAM n n n, n+1

†

n+p

External n+nd n+nd n+nd n+1+p+nd

†

If the operand and the code are in the same SARAM block.

Example 1 SUBT DAT127 ;(DP = 5: addresses 0280h–02FFh)

Before Instruction After Instruction

Data Memory Data Memory

2FFh 06h 2FFh 06h

TREG 08h TREG 08h

ACC X 0FDA5h ACC 1 0F7A5h

Example 2 SUBT *

Before Instruction After Instruction

ARP 1 ARP 1

AR1 800h AR1 800h

Data Memory Data Memory

800h 01h 800h 01h

TREG 08h TREG 08h

ACC X 0h ACC 0 FFFFFF00h

Cycles
