TBLR

Table Read

7-188

Cycles for a Repeat (RPT) Execution of a TBLR Instruction (Continued)

Program

Operand ROM DARAM SARAM External

Source: DARAM/ROM

Destination: SARAM

n+2 n+2 n+2

n+4

†

n+2+p

code

Source: SARAM

Destination: SARAM

n+2

‡

n+2

‡

n+2

‡

2n+2

n+2+p

code

‡

Source: External

Destination: SARAM

n+2+np

src

n+2+np

src

n+2+np

src

n+4+np

src

†

n+2+np

src

code

Source: DARAM/ROM

Destination: External

2n+2+nd

dst

2n+2+nd

dst

2n+2+nd

dst

2n+4+nd

dst

code

Source: SARAM

Destination: External

2n+2+nd

dst

2n+2+nd

dst

2n+2+nd

dst

2n+4+nd

dst

code

Source: External

Destination: External

4n+np

src

+nd

dst

4n+np

src

+nd

dst

4n+np

src

+nd

dst

4n+2+np

src

+nd

dst

code

†

If the destination operand and the code are in the same SARAM block

‡

If both the source and the destination operands are in the same SARAM block

If both operands and the code are in the same SARAM block

Example 1 TBLR DAT6 ;(DP = 4: addresses 0200h–027Fh)

Before Instruction After Instruction

ACC 23h ACC 23h

Program Memory Program Memory

23h 306h 23h 306h

Data Memory Data Memory

206h 75h 206h 306h

Example 2 TBLR *,AR7

Before Instruction After Instruction

ARP 0 ARP 7

AR0 300h AR0 300h

ACC 24h ACC 24h

Program Memory Program Memory

24h 307h 24h 307h

Data Memory Data Memory

300h 75h 300h 307h
