TRAP

Software Interrupt

7-192

Syntax TRAP

Operands None

Opcode

0123456789101112131415

1000101001111101

Execution (PC) + 1 → stack

22h → PC

Status Bits Not affected by INTM; does not affect INTM.

Description The TRAP instruction is a software interrupt that transfers program control to

program-memory location 22h and pushes the program counter (PC) plus 1

onto the hardware stack. The instruction at location 22h may contain a branch

instruction to transfer control to the TRAP routine. Putting (PC + 1) onto the

stack enables a return instruction to pop the return address (which points to

the instruction after TRAP) from the stack. The TRAP instruction is not mask-

able.

Words 1

Cycles for a Single TRAP Instruction

ROM DARAM SARAM External

4 4 4 4+3p

†

The processor performs speculative fetching by reading two additional instruction words. If the

PC discontinuity is taken, these two instruction words are discarded.

Example TRAP ;PC + 1 is pushed onto the stack, and then

;control is passed to program memory location

;22h.

Cycles
