Instruction Set Comparison Table
B-6
B.3 Instruction Set Comparison Table
Syntax
1x 2x 2xx 5x Description
ABS
√
√
√
√
Absolute Value of Accumulator
If the contents of the accumulator are less than zero,
replace the contents with the 2s complement of the
contents. If the contents are ≥ 0, the accumulator is not
affected.
ADCB
√
Add ACCB to Accumulator With Carry
Add the contents of the ACCB and the value of the
carry bit to the accumulator. If the result of the addition
generates a carry from the accumulator’s MSB, the
carry bit is set to 1.
ADD
dma
 [
, shift
]
ADD {
ind
}
[
, shift
[
, next ARP
]]
ADD #
k
ADD #
 lk
 [
, shift2
]
√
√
√
√
√
√
√
√
√
√
√
√
Add to Accumulator With Shift
TMS320C1x and TMS320C2x devices: Add the con-
tents of the addressed data-memory location to the ac-
cumulator; if a shift is specified, left shift the contents
of the location before the add. During shifting, low-
order bits are zero filled, and high-order bits are sign
extended.
TMS320C2xx and TMS320C5x devices: Add the con-
tents of the addressed data-memory location or an im-
mediate value to the accumulator; if a shift is specified,
left shift the data before the add. During shifting, low-
order bits are zero filled, and high-order bits are sign
extended if SXM = 1.
ADDB
√
Add ACCB to Accumulator
Add the contents of the ACCB to the accumulator.
ADDC
dma
ADDC {
ind
}
[
, next ARP
]
√
√
√
√
√
√
Add to Accumulator With Carry
Add the contents of the addressed data-memory loca-
tion and the carry bit to the accumulator.
ADDH
dma
ADDH {
ind
}
[
, next ARP
]
√
√
√
√
√
√
√
√
Add High to Accumulator
Add the contents of the addressed data-memory loca-
tion to the 16 MSBs of the accumulator. The LSBs are
not affected. If the result of the addition generates a
carry, the carry bit is set to 1.
TMS320C2x, TMS320C2xx, and TMS320C5x de-
vices: If the result of the addition generates a carry
from the accumulator’s MSB, the carry bit is set to 1.
