User's Guide

SLVU760A–August 2012–Revised January 2013

TPS25910EVM-088 EVM: Evaluation Module for the

TPS25910

This User’s Guide describes the TPS25910EVM-088 evaluation module (EVM) for the TPS25910. The

TPS25910 is a 3-V through 20-V, high-current load switch with programmable inrush slew rate.

Contents

1 Introduction .................................................................................................................. 2

1.1 Features ............................................................................................................. 2

1.2 Applications ......................................................................................................... 2

2 Description ................................................................................................................... 2

3 Schematic .................................................................................................................... 3

4 General Configuration and Description .................................................................................. 4

4.1 Physical Access .................................................................................................... 4

4.2 Test Setup .......................................................................................................... 4

5 EVM Assembly Drawings and Layout Guidelines ...................................................................... 4

5.1 PCB Drawings ...................................................................................................... 4

6 Bill of Materials .............................................................................................................. 7

List of Figures

1 TPS25910EVM-088 Schematic ........................................................................................... 3

2 Typical TPS25910EVM-088 Test Setup ................................................................................. 4

3 Top-Side Placement ........................................................................................................ 5

4 Top-Side Routing ........................................................................................................... 5

5 Bottom-Side Routing........................................................................................................ 6

6 Bottom-Side Placement .................................................................................................... 6

List of Tables

1 Connector Functionality .................................................................................................... 4

2 Test Points ................................................................................................................... 4

3 Jumper ....................................................................................................................... 4

4 TPS25910EVM-088 Bill of Materials .................................................................................... 7

SLVU760A–August 2012–Revised January 2013 TPS25910EVM-088 EVM: Evaluation Module for the TPS25910

Submit Documentation Feedback

Summary of content (12 pages)

PAGE 1
User's Guide SLVU760A – August 2012 – Revised January 2013 TPS25910EVM-088 EVM: Evaluation Module for the TPS25910 This User’s Guide describes the TPS25910EVM-088 evaluation module (EVM) for the TPS25910. The TPS25910 is a 3-V through 20-V, high-current load switch with programmable inrush slew rate. 1 2 3 4 5 6 Contents Introduction .................................................................................................................. 1.1 Features ..........................................
PAGE 2
Introduction 1 www.ti.com Introduction The TPS25910EVM allows reference circuit evaluation of the TI TPS25910 high-current load switch. 1.1 Features • • • • • • • • • 1.
PAGE 3
Schematic www.ti.com Schematic D3 BAS21 R3 30.1k EN/ TP2 1 S1 ENABLE R5 10k 1 2 3 TP1 VIN 4 VIN 3 to 20 Volts J2 + D1 SMAJ20A TP10 GND C1 47uF 0.1uF C6 R1 40.2k TP7 GND 1 2 3 4 5 6 7 8 U1 TPS25910RSA VIN EN VIN FLT VIN GND GATE GND GND OUT GND OUT ILIM OUT GND GND PWPD C2 FLT/ TP6 16 15 14 13 12 11 10 9 TP3 OUT 3 R4 0 CSD17313Q2 7 4 1 2 DISABLE 1000pF 17 J1 R2 20k TP5 GATE 1 3 3 Q1 1 2 5 6 8 J3 1 TP4 VOUT 4 2 3 4 J5 C4 0.
PAGE 4
General Configuration and Description www.ti.com 4 General Configuration and Description 4.1 Physical Access Table 1 lists the EVM connector functionality, Table 2 describes the test point availability and Table 3 describes the jumper functionality. Table 1. Connector Functionality Connector Label J1/J2 VIN/GND Description J3/J4 VOUT/GND 3 V–20 V input to the EVM 3 V–20 V output from the EVM Table 2.
PAGE 5
EVM Assembly Drawings and Layout Guidelines www.ti.com Figure 3. Top-Side Placement Figure 4.
PAGE 6
EVM Assembly Drawings and Layout Guidelines www.ti.com Figure 5. Bottom-Side Routing Figure 6.
PAGE 7
Bill of Materials www.ti.com 6 Bill of Materials Table 4. TPS25910EVM-088 Bill of Materials Count RefDes Value Description Size Part Number Supplier 2 C1 C4 0.1 µF Capacitor, ceramic, 35 V, X7R, 10% 603 STD STD 1 C2 1000 pF Capacitor, ceramic, 25 V, X7R, 10% 603 STD STD 1 C5 10 nF Capacitor, ceramic, 35 V, X7R, 10% 603 STD STD 2 C3 C6 47 µF Capacitor, aluminum, 50 V, 20% 0.
PAGE 8
