www.ti.com Bill of Materials
6 Bill of Materials
Table 4. TPS25910EVM-088 Bill of Materials
Count RefDes Value Description Size Part Number Supplier
2 C1 C4 0.1 µF Capacitor, ceramic, 35 V, X7R, 10% 603 STD STD
1 C2 1000 pF Capacitor, ceramic, 25 V, X7R, 10% 603 STD STD
1 C5 10 nF Capacitor, ceramic, 35 V, X7R, 10% 603 STD STD
2 C3 C6 47 µF Capacitor, aluminum, 50 V, 20% 0.248 inch diameter EKMG500ELL470MF11D United Chemi-Con
0 D3 BAS21 Diode, switching, 200 mA, 200 V, 250 mW SOT23 BAS21-7-F Diodes
1 D2 MBR130 Diode, Schottky, 1000 mA, 30 V SOD123 MBR130LSFT1G ON Semi
1 D1 SMAJ20A Diode, SMT TVS 400 W, 1 A, 20 V SMA SMAJ20A-13-F Diodes
1 J5 PEC02SAAN Header, male 2-pin, 100-mil spacing 0.100 in × 2 PEC02SAAN Sullins
1 R4 0 Ω Resistor, 0.0 Ω, 1 W 2512 STD STD
1 R1 40.2 kΩ Resistor, chip, 1/10W, 1% 603 STD STD
1 R2 20 kΩ Resistor, chip, 1/10W, 1% 603 STD STD
1 R3 30.1 kΩ Resistor, chip, 1/10W, 1% 603 STD STD
1 R5 10 kΩ Resistor, chip, 1/10W, 1% 603 STD STD
1 S1 09.03201.02 Switch, SPDT, slide, PC-mount, 500 mA 0.400 × 0.100 in 09.03201.02 EAO
4 J1-4 7693 Screw terminal 0.310 × 0.310 in 7693 Keystone
10 TP1-10 5012 Test point, white, thru hole 0.125 × 0.125 in 5012 Keystone
1 U1 TPS25910RSA IC, 3-V to 20-V integrated FET load switch QFN-16 TPS25910RSA TI
0 Q1 CSD17313Q2 Trans, N-Channel, 30 V, 5 A, 26 mΩ SuperSOT-6 CSD17313Q2 TI
1 -- PCB, 2.5 in × 2.0 in × 0.062 in PWR088 Any
