TPS54610

SLVS398F – JUNE 2001 – REVISED APRIL 2007

3-V TO 6-V INPUT, 6-A OUTPUT SYNCHRONOUS BUCK PWM

SWITCHER WITH INTEGRATED FETs (SWIFT™)

• 30-m Ω , 12-A Peak MOSFET Switches for High

As a member of the SWIFT™ family of dc/dc

Efficiency at 6-A Continuous Output Source

regulators, the TPS54610 low-input voltage

or Sink Current

high-output current synchronous buck PWM

converter integrates all required active components.

• Adjustable Output Voltage Down to 0.9 V With

Included on the substrate with the listed features are

1.0% Accuracy

a true, high performance, voltage error amplifier that

• Wide PWM Frequency: Fixed 350 kHz, 550 kHz

enables maximum performance and flexibility in

or Adjustable 280 kHz to 700 kHz

choosing the output filter L and C components; an

under-voltage-lockout circuit to prevent start-up until

• Synchronizable to 700 kHz

the input voltage reaches 3 V; an internally or

• Load Protected by Peak Current Limit and

externally set slow-start circuit to limit inrush

Thermal Shutdown

currents; and a power good output useful for

• Integrated Solution Reduces Board Area and

processor/logic reset, fault signaling, and supply

Component Count

sequencing.

• SWIFT Documentation, Application Notes, and

The TPS54610 is available in a thermally enhanced

Design Software: www.ti.com/swift

28-pin TSSOP (PWP) PowerPAD™ package, which

eliminates bulky heatsinks. TI provides evaluation

modules and the SWIFT™ designer software tool to

aid in quickly achieving high-performance power

• Low-Voltage, High-Density Distributed Power

supply designs to meet aggressive equipment

Systems

development cycles.

• Point of Load Regulation for High

Performance DSPs, FPGAs, ASICs and

Microprocessors

• Broadband, Networking and Optical

Communications Infrastructure

• Portable Computing/Notebook PCs

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas

Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

SWIFT, PowerPAD are trademarks of Texas Instruments.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

Summary of content (24 pages)
