TPS7A45xx
www.ti.com
SLVS720D –JUNE 2008–REVISED AUGUST 2011
LOW-NOISE FAST-TRANSIENT-RESPONSE 1.5-A LOW-DROPOUT VOLTAGE
REGULATORS
Check for Samples: TPS7A45xx
1
FEATURES
DESCRIPTION
• Optimized for Fast Transient Response
The TPS7A45xx devices are low-dropout (LDO)
• Output Current: 1.5 A
regulators optimized for fast transient response. The
• High Output Voltage Accuracy : 1% at 25°C
device can supply 1.5 A of output current with a
dropout voltage of 300 mV. Operating quiescent
• Dropout Voltage: 300 mV
current is 1 mA, dropping to less than 1 μA in
• Low Noise: 35 μV
RMS
(10 Hz to 100 kHz)
shutdown. Quiescent current is well controlled; it does
• High Ripple Rejection: 68 dB at 1KHz
not rise in dropout, as with many other regulators. In
addition to fast transient response, the TPS7A45xx
• 1-mA Quiescent Current
regulators have very low output noise, which makes
• No Protection Diodes Needed
them ideal for sensitive RF supply applications.
• Controlled Quiescent Current in Dropout
Output voltage range is from 1.21 V to 20 V. The
• Fixed Output Voltages: 1.5 V, 1.8 V, 2.5 V, 3.3 V
TPS7A45xx regulators are stable with output
• Adjustable Output from 1.21 V to 20 V
capacitance as low as 10 μF. Small ceramic
capacitors can be used without the necessary
• Less Than 1-μA Quiescent Current in
addition of ESR, as is common with other regulators.
Shutdown
Internal protection circuitry includes reverse-battery
• Stable with 10-μF Ceramic Output Capacitor
protection, current limiting, thermal limiting, and
• Reverse-Battery Protection
reverse-current protection. The devices are available
in fixed output voltages of 1.5 V, 1.8 V, 2.5 V, 3.3 V,
• Reverse Current Protection
and as an adjustable device with a 1.21-V reference
voltage. The TPS7A45xx regulators are available in
APPLICATIONS
the 5-pin TO-263 (KTT) and 6-pin TO-223 (DCQ)
• Industrial
packages.
• Wireless Infrastructure
• Radio-Frequency Systems
1
