SECAM 2x10-Bit Digital Video Decoder (Rev. A

Introduction

SLES140A—March 2007TVP5147M1PFP

1.1 Detailed Functionality

• Two 30-MSPS, 10-bit A/D channels with programmable gain control

• Supports NTSC (J, M, 4.43), PAL (B, D, G, H, I, M, N, Nc, 60) and SECAM (B, D, G, K, K1, L) CVBS, and

S-video

• Supports analog component YPbPr video format with embedded sync

• 10 analog video input terminals for multisource connection

• Supports analog video output

• User-programmable video output formats

− 10-bit ITU-R BT.656 4:2:2 YCbCr with embedded syncs

− 10-bit 4:2:2 YCbCr with separate syncs

− 20-bit 4:2:2 YCbCr with separate syncs

−2× sampled raw VBI data in active video during a vertical blanking period

− Sliced VBI data during a vertical blanking period or active video period (full field mode)

• HSYNC/VSYNC outputs with programmable position, polarity, width, and field ID (FID) output

• Composite and S-video processing

− Adaptive 2-D 5-line adaptive comb filter for composite video inputs; chroma-trap available

− Automatic video standard detection (NTSC/PAL/SECAM) and switching

− Luma-peaking with programmable gain

− Patented chroma transient improvement (CTI)

− Patented architecture for locking to weak, noisy, or unstable signals

− Single 14.31818-MHz reference crystal for all standards

− Line-locked internal pixel sampling clock generation with horizontal and vertical lock signal outputs

− Genlock output RTC format for downstream video encoder synchronization

• Certified Macrovision copy protection detection
