SECAM 2x10-Bit Digital Video Decoder (Rev. A

Introduction

SLES140A—March 2007 TVP5147M1PFP

• VBI data processor

− Teletext (NABTS, WST)

− CC and extended data service (EDS)

− Wide screen signaling (WSS)

− Copy generation management system (CGMS)

− Video program system (VPS/PDC)

− Vertical interval time code (VITC)

− Gemstar 1×/2× mode

− V-Chip decoding

− Register readback of CC, WSS (CGMS), VPS/PDC, VITC and Gemstar 1×/2× sliced data

• I

C host port interface

• Reduced power consumption: 1.8-V digital core, 3.3-V for digital I/O, and 1.8-V/3.3 V analog core with

power-save and power-down modes

• 80-terminal TQFP PowerPAD package

1.2 TVP5147M1 Applications

• DLP projectors

• Digital TV

• LCD TV/monitors

• DVD recorders

• PVR

• PC video cards

• Video capture/video editing

• Video conferencing

1.3 Related Products

• TVP5146M2 NTSC/PAL/SECAM 2y10-Bit Digital VIdeo Decoder With MacrovisionE Detection,

YPbPr/RGB Inputs, and 5-Line Comb Filter (SLES141)

• TVP5150AM1 Ultralow Power NTSC/PAL/SECAM Video Decoder With Robust Sync Detector (SLES098)

1.4 Ordering Information

PACKAGED DEVICES

80-TERMINAL PLASTIC

FLAT-PACK PowerPADE PACKAGE

0°C to 70°C TVP5147M1PFP

Gemstar is a trademark of Gemstar-TV Guide Intermational.

owerPAD is a trademark of Texas Instruments.
