- TVP5147M1PFP NTSC/PAL/SECAM 2x10-Bit Digital Video Decoder (Rev. A

Functional Description
28
SLES140A—March 2007TVP5147M1PFP
Table 2−10. I
2
C Register Summary (Continued)
REGISTER NAME I
2
C SUBADDRESS DEFAULT R/W
VBLK start line 22h−23h 001h R/W
VBLK stop line 24h−25h 015h R/W
Reserved 26h−2Ah
Overlay delay 2Bh 00h R/W
Reserved 2Ch
CTI delay 2Dh 00h R/W
CTI control 2Eh 00h R/W
Reserved 2Fh−31h
Sync control 32h 00h R/W
Output formatter 1 33h 40h R/W
Output formatter 2 34h 00h R/W
Output formatter 3 35h FFh R/W
Output formatter 4 36h FFh R/W
Output formatter 5 37h FFh R/W
Output formatter 6 38h FFh R/W
Clear lost lock detect 39h 00h R/W
Status 1 3Ah R
Status 2 3Bh R
AGC gain status 3Ch−3Dh R
Reserved 3Eh
Video standard status 3Fh R
GPIO input 1 40h R
GPIO input 2 41h R
Reserved 42h−45h
AFE coarse gain for CH1 46h 20h R/W
AFE coarse gain for CH2 47h 20h R/W
AFE coarse gain for CH3 48h 20h R/W
AFE coarse gain for CH4 49h 20h R/W
AFE fine gain for Pb 4Ah−4Bh 900h R/W
AFE fine gain for chroma 4Ch−4Dh 900h R/W
AFE fine gain for Pr 4Eh−4Fh 900h R/W
AFE fine gain for CVBS_Luma 50h−51h 900h R/W
Reserved 52h−56h
Field ID control 57h 00h R/W
Reserved 58h−68h
F-bit and V-bit control 1 69h 00h R/W
Reserved 6Ah−6Bh
Back-end AGC control 6Ch 08h R/W
Reserved 6Dh−6Eh
AGC decrement speed control 6Fh 04h R/W
ROM version 70h R
Reserved 71h−73h
AGC white peak processing 74h 00h R/W
NOTE: R = Read only
W = Write only
R/W = Read and write
Reserved register addresses must not be written to.
