- TVP5147M1PFP NTSC/PAL/SECAM 2x10-Bit Digital Video Decoder (Rev. A
Electrical Specifications
80
SLES140A—March 2007TVP5147M1PFP
3.3 Electrical Characteristics
For minimum/maximum values: IOV
DD
= 3 V to 3.6 V, DV
DD
= 1.65 V to 1.95 V, AV
DD33
= 3 V to 3.6 V,
AV
DD18
= 1.65 V to 1.95 V, T
A
= 0°C to 70°C
For typical values: IOV
DD
= 3.3 V, DV
DD
= 1.8 V, AV
DD33
= 3.3 V, AV
DD18
= 1.8 V, T
A
= 25°C
3.3.1 DC Electrical Characteristics (see Note 1)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
I
DDIO(D)
3.3-V IO digital supply current
CVBS 6
mA
I
DDIO(D
)
3.3-V IO digital supply current
S-video
6
mA
I
DD(D)
1.8-V digital supply current
CVBS 55
mA
I
DD(D)
1.8-V digital supply current
S-video
55
mA
I
DD33(A)
3.3-V analog supply current
CVBS 24
mA
I
DD33(A
)
3.3-V analog supply current
S-video
39
mA
I
DD18(A)
1.8-V analog supply current
CVBS 79
mA
I
DD18(A
)
1.8-V analog supply current
S-video
135
mA
P
TOT
Total power dissipation (normal operation) S-video 490 mW
P
SAVE
Total power dissipation (power save) 100 mW
P
DOWN
Total power dissipation (power down) 10 mW
I
lkg
Input leakage current 10 µA
C
i
Input capacitance By design 8 pF
V
OH
Output voltage high 0.8 IOV
DD
V
V
OL
Output voltage low 0.2 IOV
DD
V
NOTE 1: Measured with a load of 10 kΩ in parallel to 15 pF.
3.3.2 Analog Processing and A/D Converters
3.3.2.1 F
s
= 30 MSPS for CH1, CH2
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
Z
i
Input impedance, analog video inputs By design 200 kΩ
C
i
Input capacitance, analog video inputs By design 10 pF
Vi(pp) Input voltage range C
coupling
= 0.1 µF 0.5 1 2 V
∆G Gain control range −6 6 dB
DNL Differential nonlinearity AFE only 0.75 1 LSB
INL Integral nonlinearity AFE only 1 2.5 LSB
Fr Frequency response Multiburst (60 IRE) −0.9 dB
XTALK Crosstalk 1 MHz −50 dB
SNR Signal-to-noise ratio, all channels 1 MHz, 1 V
P-P
54 dB
GM Gain match (Note 1) Full scale, 1 MHz 1.5%
NS Noise spectrum Luma ramp (100 kHz to full, tilt-null) −58 dB
DP Differential phase Modulated ramp 0.5 °
DG Differential gain Modulated ramp ±1.5%
V
O
Output voltage C
L
= 10 pF 2 2.4 V
NOTE 1: Component inputs only
