E-39
General Operation
Using the Quick Menu
This function permits frequently used adjustments to be
performed quickly.
Note that the Quick Menu will not be displayed unless the signal
of the connected equipment is input. Please select the input that
you wish to adjust.
(1) A press of the QUICK MENU button brings up the quick
adjustment display.
Further presses cause the adjustment display to change in
sequence.
The adjustment display can be selected with use of either the
SELECT 왖 or 왔 button.
(2) Press the cursor 왗 or 왘 button to make the adjustment.
(3) To close the display immediately, press the CANCEL but-
ton.
In the absence of operations for a period of about 10 sec-
onds, the display will close automatically.
Brightness Adjusts the brightness of the image. See page E-47.
Contrast Adjusts the contrast of the image. See page E-47.
Keystone Corrects (vertical) keystone distortion of the screen. See page E-31.
Volume This function adjusts the volume of the built-in speaker. See page E-31.
Presentation timer Sets the time of the presentation timer. See page E-33.
Quick Color Adj. Select the preset color mode. See page E-49
Content of Adjustments and Settings
Example: Brightness adjustment display
Display Item Adjustment/Setting
RGB
STANDBY
VIDEO
FREEZE
MUTE
ECO AUTO
ASPECT
TIMER
VOL KSTN ZOOM
CANCEL
MENU
ENTER
1234
QUICK
Q
FREEZE
MUTE
LASER
AUTO
TIMER
VOL
ZOOM
RGB
VIDEO
R-CLICK/
CANCEL
MENU
ENTER
STANDBY
12
34
R-CLICK/
CANCEL
QUICK
Q
(1)
(2)
(3)
(2)
(1)
(3)
