UCC27517

UCC27516

www.ti.com

SLUSAY4C – MARCH 2012–REVISED MAY 2013

Single-Channel High-Speed Low-Side Gate Driver

(with 4-A Peak Source and 4-A Peak Sink)

Check for Samples: UCC27517, UCC27516

FEATURES

APPLICATIONS

• Low-Cost Gate-Driver Device Offering Superior • Switch-Mode Power Supplies

Replacement of NPN and PNP Discrete

• DC-to-DC Converters

Solutions

• Companion Gate-Driver Devices for Digital-

• 4-A Peak-Source and 4-A Peak-Sink

Power Controllers

Symmetrical Drive

• Solar Power, Motor Control, UPS

• Fast Propagation Delays (13-ns typical)

• Gate Driver for Emerging Wide Band-Gap

• Fast Rise and Fall Times (9-ns and 7-ns

Power Devices (such as GaN)

typical)

• 4.5 to 18-V Single-Supply Range DESCRIPTION

The UCC27516 and UCC27517 single-channel high-

• Outputs Held Low During VDD UVLO (ensures

speed low-side gate driver devices are capable of

glitch-free operation at power up and power

effectively driving MOSFET and IGBT power

down)

switches. Using a design that inherently minimizes

• TTL and CMOS Compatible Input-Logic

shoot-through current, UCC27516 and UCC27517

Threshold (independent of supply voltage)

are capable of sourcing and sinking high peak-current

• Hysteretic-Logic Thresholds for High-Noise

pulses into capacitive loads offering rail-to-rail drive

capability and extremely small propagation delay

Immunity

typically 13 ns.

• Dual Input Design (choice of an inverting (IN-

pin) or non-inverting (IN+ pin) driver

The UCC27516 and UCC27517 provides 4-A source,

4-A sink (symmetrical drive) peak-drive current

configuration)

capability at VDD = 12 V.

– Unused Input Pin can be Used for Enable

or Disable Function

The UCC27516 and UCC27517 is designed to

operate over a wide VDD range of 4.5 to 18 V and

• Output Held Low when Input Pins are Floating

wide temperature range of –40°C to 140°C. Internal

• Input Pin Absolute Maximum Voltage Levels

Undervoltage Lockout (UVLO) circuitry on VDD pin

Not Restricted by VDD Pin Bias Supply

holds output low outside VDD operating range. The

Voltage

capability to operate at low voltage levels such as

• Operating Temperature Range of –40°C to

below 5 V, along with best-in-class switching

characteristics, is especially suited for driving

+140°C

emerging wide band-gap power-switching devices

• 5-Pin DBV (SOT-23) and 6-Pin DRS (3 mm × 3

such as GaN power semiconductor devices.

mm WSON with exposed thermal pad)

Package Options

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

Summary of content (31 pages)

PAGE 1
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 Single-Channel High-Speed Low-Side Gate Driver (with 4-A Peak Source and 4-A Peak Sink) Check for Samples: UCC27517, UCC27516 FEATURES APPLICATIONS • • • • 1 • • • • • • • • • • • • Low-Cost Gate-Driver Device Offering Superior Replacement of NPN and PNP Discrete Solutions 4-A Peak-Source and 4-A Peak-Sink Symmetrical Drive Fast Propagation Delays (13-ns typical) Fast Rise and Fall Times (9-ns and 7-ns typical) 4.
PAGE 2
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com TYPICAL APPLICATION DIAGRAMS Inverting Input Non-Inverting Input Q1 Q1 UCC27517 UCC27517 4.5 V to 18 V 4.
PAGE 3
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 ABSOLUTE MAXIMUM RATINGS (1) (2) (3) over operating free-air temperature range (unless otherwise noted) Supply voltage range OUT voltage MIN MAX VDD -0.3 20 DC -0.3 VDD + 0.3 Repetitive pulse less than 200 ns (4) Output continuous current IOUT_DC (source/sink) Output pulsed current (0.
PAGE 4
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com RECOMMENDED OPERATING CONDITIONS over operating free-air temperature range (unless otherwise noted) MIN TYP Supply voltage range, VDD 4.5 12 18 V Operating junction temperature range -40 140 °C 0 18 V Input voltage, IN+ and IN- MAX UNIT ELECTRICAL CHARACTERISTICS VDD = 12 V, TA = TJ = -40°C to 140°C, 1-µF capacitor from VDD to GND. Currents are positive into, negative out of the specified terminal.
PAGE 5
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 ELECTRICAL CHARACTERISTICS (continued) VDD = 12 V, TA = TJ = -40°C to 140°C, 1-µF capacitor from VDD to GND. Currents are positive into, negative out of the specified terminal. PARAMETER TEST CONDITION MIN TYP MAX VDD = 12 V CLOAD = 1.8 nF 8 12 VDD = 4.5 V CLOAD = 1.8 nF 16 22 VDD = 12 V CLOAD = 1.8 nF 7 11 VDD=4.5V CLOAD = 1.
PAGE 6
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com High INPUT (IN- pin) Low High IN+ pin Low 90% OUTPUT 10% tD2 tf tD2 tr Figure 2. Inverting Configuration (PWM input to IN- pin (IN+ pin tied to VDD)) High INPUT (IN- pin) Low High ENABLE (IN+ pin) Low 90% OUTPUT 10% tD1 tr tD1 tf Figure 3.
PAGE 7
UCC27517 UCC27516 www.ti.
PAGE 8
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com TERMINAL FUNCTIONS (UCC27516) TERMINAL I/O FUNCTION PIN NUMBER NAME 1 IN- I Inverting Input: When the driver is used in non-inverting configuration, connect INto GND in order to enable output, OUT held LOW if IN- is unbiased or floating. 2, 3 GND - Ground: All signals referenced to this pin. TI recommends to connect pin 2 and pin 3 on PCB as close to the device as possible. 4 VDD I Bias supply input.
PAGE 9
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 TYPICAL CHARACTERISTICS STARTUP CURRENT vs TEMPERATURE OPERATING SUPPLY CURRENT vs TEMPERATURE (Output Switching) 0.12 4 IN+=Low,IN−=Low IN+=High, IN−=Low 3.5 0.1 IDD (mA) Startup Current (mA) 0.11 0.09 0.08 0.07 VDD = 3.4 V 0.05 −50 0 50 Temperature (°C) 100 2 −50 150 0 G001 50 Temperature (°C) 100 150 G013 Figure 5. Figure 6.
PAGE 10
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com TYPICAL CHARACTERISTICS (continued) OUTPUT PULLDOWN RESISTANCE vs TEMPERATURE RISE TIME vs TEMPERATURE 1 8 VDD = 12 V CLoad = 1.8 nF 0.8 7 Rise Time (ns) Pull−Down Resistance (Ω) ROL 0.6 0.4 6 5 0.
PAGE 11
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 TYPICAL CHARACTERISTICS (continued) RISE TIME vs SUPPLY VOLTAGE FALL TIME vs SUPPLY VOLTAGE 20 10 Fall Time (ns) Rise Time (ns) 8 15 10 6 4 5 0 4 8 12 Supply Voltage (V) 16 20 2 0 G008 Figure 17. 4 8 12 Supply Voltage (V) 16 20 G009 Figure 18. APPLICATION INFORMATION Introduction High-current gate-driver devices are required in switching power applications for a variety of reasons.
PAGE 12
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com UCC2751x Product Family The UCC2751x family of gate-driver products (Table 3) represent Texas Instruments’ latest generation of singlechannel low-side high-speed gate-driver devices featuring high-source/sink current capability, industry best-inclass switching characteristics and a host of other features (Table 4), all of which combine to ensure efficient, robust, and reliable operation in high-frequency switching power circuits.
PAGE 13
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 Typical Application Diagram Typical application diagrams of the UCC27516 and UCC27517 devices are shown below illustrating use in noninverting and inverting driver configurations. Q1 UCC27516 UCC27517 4.5 V to 18 V 1 IN- IN+ 4 2 GND OUT 5 3 GND VDD 4 Q1 VIN+ R1 V+ R1 1 VDD 2 GND 3 IN+ OUT 5 IN- 4 C1 4.5 V to 18 V VIN+ IN+ C1 Figure 19.
PAGE 14
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com VDD and Undervoltage Lockout The UCC2751x devices have internal Undervoltage Lockout (UVLO) protection feature on the VDD-pin supplycircuit blocks. Whenever the driver is in UVLO condition (for example when VDD voltage is less than VON during power up and when VDD voltage is less than VOFF during power down), this circuit holds all outputs LOW, regardless of the status of the inputs. The UVLO is typically 4.
PAGE 15
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 Input Stage The input pins of the UCC27516 and UCC27517 devices are based on a TTL/CMOS compatible input-threshold logic that is independent of the VDD supply voltage. With typ high threshold = 2.2 V and typ low threshold = 1.2 V, the logic-level thresholds can be conveniently driven with PWM-control signals derived from 3.3-V and 5-V digital-power controllers.
PAGE 16
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com Enable Function As mentioned earlier, an enable/disable function is easily implemented in the UCC27516 and UCC27517 using the unused input pin. When IN+ is pulled down to GND or IN- is pulled down to VDD, the output is disabled. Thus IN+ pin is used like an enable pin that is based on active-high logic, while IN- can be used like an enable pin that is based on active-low logic.
PAGE 17
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 Power Dissipation Power dissipation of the gate driver has two portions as shown in Equation 1. PDISS = PDC + PSW (1) The DC portion of the power dissipation is PDC = IQ x VDD where IQ is the quiescent current for the driver.
PAGE 18
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 • 18 www.ti.com RON (effective resistance of pull-up structure) = 1.
PAGE 19
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 Low Propagation Delays The UCC27516 and UCC27517 driver devices feature best-in-class input-to-output propagation delay of 13 ns (typ) at VDD = 12 V. This promises the lowest level of pulse-transmission distortion available from industrystandard gate-driver devices for high-frequency switching applications.
PAGE 20
UCC27517 UCC27516 SLUSAY4C – MARCH 2012 – REVISED MAY 2013 www.ti.com PCB Layout Proper PCB layout is extremely important in a high-current fast-switching circuit to provide appropriate device operation and design robustness. The UCC27516 and UCC27517 gate driver incorporates short-propagation delays and powerful output stages capable of delivering large current peaks with very fast rise and fall times at the gate of the power switch to facilitate voltage transitions very quickly.
PAGE 21
UCC27517 UCC27516 www.ti.com SLUSAY4C – MARCH 2012 – REVISED MAY 2013 REVISION HISTORY Changes from Revision B (June 2012) to Revision C • Page Added 0.5 to beginning of PSW equation in Power Dissipation section ............................................................................... 18 Changes from Revision A (March 2012) to Revision B Page • Added UCC27516 device. ................................................................................................................................
PAGE 22
PACKAGE OPTION ADDENDUM www.ti.
PAGE 23
PACKAGE OPTION ADDENDUM www.ti.com 21-May-2014 Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided. TI bases its knowledge and belief on information provided by third parties, and makes no representation or warranty as to the accuracy of such information. Efforts are underway to better integrate information from third parties.
PAGE 24
PACKAGE MATERIALS INFORMATION www.ti.com 11-Jun-2014 TAPE AND REEL INFORMATION *All dimensions are nominal Device UCC27516DRSR Package Package Pins Type Drawing SON DRS 6 SPQ Reel Reel A0 Diameter Width (mm) (mm) W1 (mm) 3000 330.0 12.4 3.3 B0 (mm) K0 (mm) P1 (mm) W Pin1 (mm) Quadrant 3.3 1.1 8.0 12.0 Q2 UCC27516DRST SON DRS 6 250 180.0 12.4 3.3 3.3 1.1 8.0 12.0 Q2 UCC27517DBVR SOT-23 DBV 5 3000 178.0 9.0 3.23 3.17 1.37 4.0 8.
PAGE 25
PACKAGE MATERIALS INFORMATION www.ti.com 11-Jun-2014 *All dimensions are nominal Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm) UCC27516DRSR SON DRS 6 3000 367.0 367.0 35.0 UCC27516DRST SON DRS 6 250 210.0 185.0 35.0 UCC27517DBVR SOT-23 DBV 5 3000 180.0 180.0 18.0 UCC27517DBVR SOT-23 DBV 5 3000 203.0 203.0 35.0 UCC27517DBVT SOT-23 DBV 5 250 180.0 180.0 18.0 UCC27517DBVT SOT-23 DBV 5 250 203.0 203.0 35.
PAGE 26
