Spec Sheet

Page 1 of 2
11 / 17
HMWB36FS
WALL HOOD WITH BLOWER (36-INCH WIDTH)
MASTERPIECE
®
SERIES
FEATURES & BENEFITS
- 600 CFM Integrated Blower included
- Recirculation possible with kit RECIRC36FS (max 600 CFM)
- Three fan speeds
- Built-in ‘Clean Filter‘ reminder light illuminates after 40 hours of
operation
GENERAL PROPERTIES
Operating Mode Convertible: Ducted /
Recirculating
Maximum CFM 600 CFM
Number of Speed Settings 3-Stage
Motor Location Integrated
Number Of Lights Lights Sold
Separately - 2
Bulb Type 50 W - GU10 Base
Total Power Of The Lamps (W) 100 W
Damper Included Yes
Grease Filter Material Washable Synthetic
Grease Filter Type Multilayer Cassette
TECHNICAL DETAILS
Watts (W) 550 W
Current (A) 15 A
Volts (V) 120 V
Frequency (Hz) 60 HZ
Plug Type Fixed Connection
DIMENSIONS & WEIGHT
Overall Appliance Dimensions (Width Of
Canopy Included) (HxWxD) (in)
11" x 36" x 23
1
/
8
"
Required Distance Above Cooktop / Range
Cooking Surface
30" / 30"
Diameter of Air Duct (in) Top 10"
Diameter of Air Duct (in) Back N/A
Net Weight (lbs) 33 lbs
ACCESSORIES (REQUIRED)
Recirculation Kit
BLOWER OPTIONS
Remote Blower
(Mounted to Roof or External Wall)
N/A
N/A
N/A
Inline Blower
(Mounted Between Kitchen and External Wall)
N/A
N/A
Integrated Blower (Mounted in Hood) N/A
N/A
WARRANTY
Limited Warranty Parts And Labor 2 Year
ACCESSORIES (OPTIONAL)
Recirculation Kit
RECIRC36FS - For Masterpiece HMWB36FS and HMWN36FS
36" Hoods Only. Adds 4" to height of appliance
Replacement Charcoal Filter - CHFILT3036
For Use With Recirculation Kit RECIRC_FS
36" W, 6" H Stainless Steel Duct Cover DC36US
36" W, 12" H Stainless Steel Duct Cover DCT36US
