PRG305PH 30 INCH GAS PRO HARMONY RANGE Specifications

ManualsBrandsThermador ManualsDomestic AppliancesPRG305PH

THERMADOR EXCLUSIVE

09 / 15

Page 1 of 5

TECHNICAL DETAILS

Circuit Breaker (A) 15 A

Volts (V) 120 V

Frequency (Hz) 60 Hz

Plug Type 120V-3 Prong

Power Cord Length (in) 72"

Energy Source Gas

Gas Type Natural Gas 15 mbar

(USA)

Alternative Gas Type Liquid Gas 27.5 mbar

(USA)

SEE PAGE 2 FOR OPTIONAL ACCESSORIES

PRG305PH

30-INCH GAS PRO HARMONY

RANGE

PROFESSIONAL SERIES, STANDARD-DEPTH, PORCELAIN COOKTOP SURFACE

Also Available:

PRL305PH - LP

FEATURES & BENEFITS

- Exclusive, patented Star

Burner–most even heating,

unsurpassed ame coverage

- QuickClean Base

designed for easy surface cleaning

- Precision simmering capabilities as low as 100°F (375 BTU)

with 2 ExtraLow

Simmer burners

- Professional style, continuous cast iron grates

- Truly Flush Mounted

™

, 24" standard cabinet depth

GENERAL PROPERTIES

Oven Capacity 4.4 cu. ft.

Cooking Modes - Main / Large Cavity

Bake, Convection Bake, Broil, Extended Bake

Cooking Modes - Small Cavity N/A

Programs Sabbath Function

Cleaning Type N/A

Type of Grate Continuous Cast Iron

Controls Metal Knobs

Sealed Burners Yes

OVEN PERFORMANCE

Bake Power 23,500 BTU (NG)

Broil Power 24,000 BTU (NG)

Convection Power N/A

BURNER PERFORMANCE

Total Number of Cooktop Burners 5

Power of Front Left Burner BTU 10,000 (NG)

Power of Back Left Burner BTU 8,000 and XLO (NG)

Power of Back Center Burner BTU 15,000 (NG)

Power of Front Center Burner BTU N/A

Power of Center 12" Electric Griddle (W) N/A

Power of Center 12" Electric Grill (W) N/A

Power of Far Right 12" Electric Griddle (W) N/A

Power of Back Right Burner BTU 8,000 (NG)

Power of Front Right Burner BTU 18,000 and XLO (NG)

DIMENSIONS & WEIGHT

Overall Appliance Dimensions (HxWxD) (in) 35

"–36

" x

" x 24

Required Cutout Size (HxWxD) (in) 35

"–36

" x 30"

x 24"

Adjustable Range Height (in.)

Net Weight (lbs) 336 lbs

ACCESSORIES (INCLUDED)

1 X Island Trim, 1 X Full Access Telescopic Rack, 2 X Standard Racks, 1 X

Broiler Pan

WARRANTY

Limited Warranty, Entire Appliance,

Parts and Labor

2 Year

Summary of content (5 pages)

PAGE 1
PRG305PH 30-INCH GAS PRO HARMONY® RANGE PROFESSIONAL SERIES, STANDARD-DEPTH, PORCELAIN COOKTOP SURFACE GENERAL PROPERTIES Oven Capacity 4.4 cu. ft.
PAGE 2
PRG305PH 30-INCH GAS PRO HARMONY® RANGE PROFESSIONAL SERIES, STANDARD-DEPTH, PORCELAIN COOKTOP SURFACE ACCESSORIES (OPTIONAL) PA12CHPBLK 12" Cutting Board PWOKRINGHC Wok Ring PAKNOBLUNH Blue Knob Pro Harmony Kit PAGRIDDLE Griddle 30-INCH RANGE DIMENSIONS PA30GLBH 9" Low Backguard 30-INCH RANGE CUTOUT DIMENSIONS Page 2 of 5 09 / 15
PAGE 3
PRG305PH 30-INCH GAS PRO HARMONY® RANGE Cabinet Clearances with Hood PROFESSIONAL SERIES, STANDARD-DEPTH, PORCELAIN COOKTOP SURFACE Clearances with Hood 30-INCH RANGE CABINETCabinet CLEARANCES WITH HOOD 30 " wid – 36 e h " (7 oo 62 d – 57 " (4 18 imum min ) mm 91 4m m) 30 " wid – 36 e h " (7 oo 62 d – 91 4m m) d . n ea i m erh . ) m ov ace 2 m of urf (76 ttom ing s 5" " 0 o ( 3 b ook ) to 127 m " if m c com m 13 0 mm n. fro d to mi ) sid bu m 3 o ) 3 o ( ew sti in. m h alls ble ixn..
PAGE 4
PRG305PH 30-INCH GAS PRO HARMONY® RANGE PROFESSIONAL SERIES, STANDARD-DEPTH, PORCELAIN COOKTOP SURFACE Cabinet Clearances with OTR Microwave 30-INCH RANGE CABINET CLEARANCES WITH OVER-THE-RANGE MICROWAVE Cabinet Clearances with OTR Microwave m) m 57 " (4 18 imum min 5" ( to 127 m c sid ombu m) m ew sti in. alls ble . ax "m 13 inet b ca th p de R m) OT ’s 7 m er to t5u"re(1r nual 5 4 f c to a27 e "( 18 imum R nufa ion cmosm. mm) a lat sidce bu m 0" n i m m tal an ewal stible in.
PAGE 5
PRG305PH 30-INCH GAS PRO HARMONY® RANGE PROFESSIONAL SERIES, STANDARD-DEPTH, PORCELAIN COOKTOP SURFACE Installation Side ClearancesREQUIREMENTS 30-INCH RANGE DIMENSIONS AND SIDE CLEARANCE NOTE: A 36-inch minimum clearance is required between the top of the cooking surface and the bottom of an unprotected cabinet. A 30-inch clearance can be used when the bottom of the wood or metal cabinet is protected by not less than 1/4 inch of a flame retardant material covered with not less than No.
