Operating instructions

ManualsBrandsThomas ManualsDomestic AppliancesTwin TT Aquafilter

1. Housing cover

2. Intake connection

3. Carry grip

4. Cover lock and release catch

5. Button, cable rewind

6. Pump on/off switch

7. Pump illuminated display

8. Fast coupling, spray hose (under the cover)

9. Appliance on and off switch including electronic

suction power controller (ONE-TOUCH key)

10. Illuminated display, electric suction power regulation

11. Furniture protection strip

12. AQUA filter (12) with foam filter (12a) and suction

filter (12b)

13. Dirty water tank (13) with wet filter (13a) and float

(13b)

14. HEPA filter

15. Motor protection filter

16. Suction tube holder (parking position)

17. Fresh water tank with removable cover

18. Mains cable plug

19. MKA microfilter

20. Small turning wheels

21. Suction tube holder (parking position)

22. Large travel wheels

Product familiarisation

9 10 11

16 17

13b

1213a 12a12b14 13b 13

Summary of content (8 pages)

PAGE 1
GB Product familiarisation 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. Housing cover Intake connection Carry grip Cover lock and release catch Button, cable rewind Pump on/off switch Pump illuminated display Fast coupling, spray hose (under the cover) Appliance on and off switch including electronic suction power controller (ONE-TOUCH key) Illuminated display, electric suction power regulation Furniture protection strip 3 2 1 7 6 8 9 10 11 14 12. 13. 14. 15.
PAGE 2
Accessories 25 24 Suction hose (23) with integrated sprayer, shut-off valve (24) and mechanical suction power controller (25) Anti-swash insert, 2-section Klick 23 Height adjustable telescopic suction tube with parking holder Carpet spraying nozzle with spraying hose Carpet and hard floor nozzle including parquet shoe Hard floor adapter Upholstery nozzle Crevice nozzle Upholstery spraying nozzle Nozzle adapter for both upholstery and crevice nozzle Window nozzle adapter HEPA filter Spraying ho
PAGE 3
We congratulate you … ... on buying the THOMAS TWIN tt AQUAFILTER, a topclass floor vacuum cleaner with which you can clean your carpets, hard floors and upholstered furniture. By purchasing your new THOMAS TWIN tt AQUAFILTER you have decided in favour of an exclusive product that sets new standards for every day vacuum cleaning.
PAGE 4
General instructions To connect up suction hose Dust vacuuming Information for use - Insert the suction hose connection piece in the appliance connector and turn backwards until it locks. - Push spraying agent hose in the fast coupling; to do this open pump cover by pressing down the bottom section. - Insert shut-off valve in the holder on the suction tube.
PAGE 5
Wash suction cleaning/ sucking up liquids Information for use ● Caution! Petrol, thinners, heating oil, etc., can develop explosive vapour and mixtures when mixed with the intake air. ● Acetone, acids and solvents can attack the materials used to produce the appliance. Clean and dirty water can be sucked up without any hesitation. ● Clean and dry the dirty water tank and all the used parts after sucking up liquids. ● Never suck up liquids without the dirty water tank.
PAGE 6
Empty the dirty water tank after you have used up all the water and completely fill the cleansing agent tank from the fresh water tank to prevent the appliance being switched off automatically. Should you not observe the above-mentioned instructions the float will automatically switch off the appliance as soon as the dirty water tank is full. (The motor will be clearly heard to be running at a higher speed. Switch off appliance, disconnect the mains plug and empty the dirty water tank.
PAGE 7
The filter can be also removed for easier cleaning when dirt and fluff have blocked the suction filter (12b); refit the suction filter after cleaning. Remove contamination and fluff on the suction connector. 2. HEPA filter Your TWIN tt AQUAFILTER is provided with a high quality HEPA filter (14), which can be cleaned several times depending on your needs and the type of dust found in your home. Clean your appliance when the suction power decreases and as when needed (at the latest every six months).
PAGE 8
What to do when ... Should your THOMAS TWIN tt AQUAFILTER not function to your satisfaction first check by means of the check list given below whether the cause of the irregularity is just a small matter before you contact the Customer Service Department.
