User's Manual

3/16
1 Removable USB cable; USB connector on
the back of the pedal set
2 Removable RJ12 cable; RJ12 connector
on the back of the pedal set
3 Medium resistance, preinstalled by default
(1 black F20 spring + 1 grey F15 spring)
(+ 1 central chrome-plated preloading spring)
(+ 2 spacers without markings)
4 1 white F10 spring
5 2 red F30 springs
6 2 spacers with red markings
(specifically designed for use with the red
F30 springs)
7 2.5 mm Allen key
8 5 flat washers (to decrease or
eliminate the preloading of the central
chrome-plated spring)
10 Plastic pedal head support for vertical
inclination of pedals
Spacers
2 types of spacers are included. It is important to use the proper type of spacer, depending on the
type of spring selected.
Spacers without color markings
(and with grooves)
For use with the following springs:
White F10
Grey F15
Black F20
Spacers with red markings
(and without grooves)
Specifically designed for use with the
following springs:
Red F30
Pedal arms and heads
9 Metal pedal arm with 4 holes
10 Plastic pedal head support (to be
positioned between the pedal head and
arm) with 4 holes
11 Metal pedal heads (with different
numbers of holes: 9 for the
accelerator pedal; 6 for the brake
pedal; 6 for the clutch pedal)
