User Manual WARNING: To ensure that your T150 racing wheel functions correctly with games, you may be required to install the game’s automatic updates (available when your system is connected to the Internet).
TECHNICAL FEATURES 1 2 3 4 5 6 7 SELECT/START buttons on PS3™ and SHARE/OPTIONS on PS4™ 8 PS button 9 Large threaded hole (for attachment system and fastening screw) 10 Attachment system 11 Metal fastening screw T150 base Wheel 2 sequential paddle shifters (up & down) Directional buttons Built-in USB sliding switch for PS4™/PS3™ MODE button + red/green indicator light 12 Steering axis 13 L3/R3 buttons 14 Power cable or Power supply connector (varies from one country to another) 15 Racing wheel USB cabl
PLUGGING THE RACING WHEEL INTO AN ELECTRICAL OUTLET: PLEASE READ BEFORE PROCEEDING! Your racing wheel’s power supply varies according to the country where you purchased your device. European versions only Important note: the European version of the T150 is equipped with an internal power supply, located directly inside the racing wheel's base.
WARNING Before using this product, please read this manual carefully and save it for later reference. * * * * * * * * * * * * Warning – Electrical shock Keep the product in a dry location and do not expose it to dust or sunlight. Do not twist or pull on the connectors and cables. Do not spill any liquid on the product or its connectors. Do not short-circuit the product. Never dismantle the product; do not throw it onto a fire and do not expose it to high temperatures.
Warning – Injuries due to force feedback and repeated movements (continued) * If the symptoms or pain indicated persist when you start playing again, stop playing and consult your doctor. * Keep out of children’s reach. * During gameplay, always leave both hands correctly positioned on the wheel without completely letting go. * During gameplay, never place your hands or your fingers under the pedals or anywhere near the pedal set.
Warning – Pedal set pinch hazard when playing * * * * Keep the pedal set out of children’s reach. During gameplay, never place your fingers on or anywhere near the sides of the pedals. During gameplay, never place your fingers on or anywhere near the pedal’s rear base. During gameplay, never place your fingers on or anywhere near the pedal’s front base. NEVER NEVER NEVER Warning – Pedal set pinch hazard when not playing * Store the pedal set in a safe place, and keep it out of children’s reach.
ADJUSTING THE PEDAL INCLINATION The pedal inclination is adjustable. The adjustment instructions for each pedal are available at http://ts.thrustmaster.com. In the Updates and Downloads section, click PlayStation® / Wheels / T150, then select Manual/Help file. ATTACHING THE RACING WHEEL Attaching the racing wheel to a table or a desktop 1. Place the racing wheel on a table or any other horizontal, flat and stable surface. 2.
ATTACHMENT / REMOVAL DIRECTION To tighten: Turn the screw anticlockwise To release: Turn the screw clockwise 8/18
Attaching the pedal set to a cockpit 1. Attach the pedal set using the small screw threads located on its underside. 2. Drive two M6 screws (not included) through the cockpit shelf, then feed them into the two small screw threads located on the underside of the pedal set. Important: The length of the two M6 screws must not exceed the thickness of the shelf + 10 mm; longer screws could cause damage to internal components located in the pedal set.
SETTING UP THE PLAYSTATION®4 RACING WHEEL FOR PLAYSTATION®3 OR 1. Connect the pedal set to the connector (17) located at the back of the racing wheel's base. 2. Connect the power supply cable to the connector (14) located at the back of the racing wheel's base. 3. Plug the power supply cable into an electrical outlet with the same voltage specifications. For more information about this, please refer to the PLUGGING THE RACING WHEEL INTO AN ELECTRICAL OUTLET section, on page 3 in this manual. 4.
SETTING UP THE RACING WHEEL FOR PC* *PC compatibility not tested nor endorsed by Sony Computer Entertainment Europe Important note: On PC, the USB sliding switch (5) on the racing wheel’s base must always be set to the PS3™ position. 1. Go to http://ts.thrustmaster.com to download the drivers and the force feedback software for PC. In the Updates and Downloads section, click PC / Wheels / T150, then select Drivers. 2.
PC MAPPING 12/18
AUTOMATIC RACING WHEEL AND PEDAL SET CALIBRATION The wheel automatically self-calibrates when you plug the racing wheel into an electrical outlet and connect the racing wheel’s USB connector to the PlayStation£3 or PlayStation£4 system. During this phase, the racing wheel will rotate quickly towards the left and the right, covering a 1080 degree angle, before stopping at the centre.
MODE BUTTON AND INDICATOR LIGHT (6) MODE button for the pedal set The pedal set included with the T150 features 2 pedals. When using this pedal set, make sure that the indicator light remains red, or else the gas pedal will not function properly. The T150 is also compatible with Thrustmaster pedal sets featuring 3 pedals (sold separately); these allow you to electronically swap the accelerator and clutch pedals. To do so, simply press the MODE button (6) for 2 seconds.
