01) REC: Enter the Record Schedule Page.
02) 0-+10 (numeric keypad): Input numbers, 0 to 10+ can
be used as a quick channel changing like a television, and
these will work during either live-viewing mode or
playback. Additionally, the numeric keypad can be used
when inputting any numerical information – most often,
your password.
03) Mute: Enabling or disabling the audio output won't
have any effect on recordings. If you've configured the
DVR to record audio, it will continue to do so while
muted.
4) Menu/II: One of the primary controls for navigating
through the menus. When in live-viewing mode, it will
enter the menu bar. When pressed while in the main
menu, it will return the DVR to live-viewing mode.
06) Play: Enter the Playback Page.
07) Tour: Recall PTZ Tour.
08) PIP: Swap Picture-in-Picture screen with the main
display.
`
09) Zoom: Zoom the picture of a selected channel.
10) Multi-Channel: Switch between multiple screens
display mode.
05) 12) 14) 17) ARROW BUTTON: Move the cursor
in the appropriate direction when navigating menus.
They’re also control buttons for the Playback page
(Fast Backward, Slow Motion, Fast Forward, Pause).
11) Lock: Lock the system, and you will need to enter the
password get into the system.
13) Esc: Exit.
15) ENTER/MODE: Use the button to select an option in
the menus or confirm an entry.
16) Auto: Enter the Auto Sequence Page.
18) OSD: Enter the Image Setting Page.
19) IRIS+ /-: PTZ camera IRIS setup.
20) PTZ: Recall PTZ control panel.
1
2
3
4
5
6
8
9
10
7
11
13
12
14
15
17
18
19
20
16
Remote Control
