User Guide

Plantronics

wireless headset

The Wireless Headset Adapter is the connection between

the

T38G/

T28/T26 IP phone and the Plantronics wireless

headset.

3.5 mm

DC Jack

RJ11 cord

RJ12 cord

www.yealink.com

——EHS36

Wireless Headset Adapter

We reserve the right to improve or change the product and the

user guide without notice.

You can also download this user guide from: http://www.yealink.com/index.php/Support/

PAGE 1
The Wireless Headset Adapter is the connection between the T38G/T28/T26 IP phone and the Plantronics wireless headset. RJ12 cord Plantronics wireless headset 3.5 mm DC Jack Wireless Headset Adapter ——EHS36 RJ11 cord We reserve the right to improve or change the product and the user guide without notice. User Guide You can also download this user guide from: http://www.yealink.com/index.php/Support/ Copyright c 2011 YEALINK NETWORK TECHNOLOGY CO.,LTD. www.yealink.
PAGE 2
Introduction The Wireless Headset Adapter——EHS36, for the control of wireless headsets is the perfect combination between Yealink IP Phone T38G/T28/T26 and wireless headsets, such as GN Netcom/Jabra/Sennheiser and Plantronics. Port 2 : Connect with the GN Netcom/Jabra/Sennheiser Wireless headset through RJ45 cord. Port 3 : Connect with the Plantronics Wireless headset through the 3.5 mm DC Jack. Cord Description RJ11 cord:For the audio connection to the IP Phone headset port and the wireless headset.
