15.4. EMC recommendations
All LE920 signals are provided with some EMC protection. Nevertheless the accepted level
differs according to which pin. The characteristics are described in the following Table:
Pad Signal I/O Function Contact Air
All Pins
All ± 4KV ± 8KV
Antenna
AD1,AU9,S1
Antenna
Pad
s
AI Antenna pad ± 8KV ± 15KV
Appropriate series resistors must be considered to protect the input lines from overvoltage.
