COMPACT SPEAKERS BS-1015BSB

BS-1015BSW

Thank you for purchasing TOA's Compact Speaker.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

Traceability Information for Europe (EMC directive 2004/108/EC)

Manufacturer:

TOA Corporation

7-2-1, Minatojima Nakamachi, Chuo-ku, Kobe, Hyogo,

Japan

Authorized representative:

TOA Electronics Europe GmbH

Suederstrasse 282, 20537 Hamburg,

Germany

INSTRUCTION MANUAL

1. SAFETY PRECAUTIONS ........................... 1

2. GENERAL DESCRIPTION

AND FEATURES ......................................... 2

3. IMPEDANCE CHANGE .............................. 2

4. WIRING ....................................................... 3

5. SPEAKER INSTALLATION ........................ 4

6. INSTALLATION PRECAUTIONS ............... 4

7. WIRING DIAGRAM ..................................... 4

8. FREQUENCY RESPONSE (1 W, 4 m) ....... 4

9. DIMENSIONAL DIAGRAM ......................... 5

10. SPECIFICATIONS ...................................... 5

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe

operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or

cautions regarding safety.

• After reading, keep this manual handy for future reference.

When Installing the Unit

• Refer all installation work to the dealer from whom

the speaker was purchased. Installation work

requires extensive technical knowledge and

experience. The speaker may fall off if incorrectly

installed, resulting in possible personal injury.

• Install the speaker only in a location that can

structurally support the full weight of the unit and

mounting bracket. Doing otherwise may result in

the speaker falling down and causing personal

injury and/or property damage.

• Since the unit is designed for in-door use, do not

install it outdoors. If installed outdoors, the aging of

parts causes the unit to fall off, resulting in personal

injury. Also, when it gets wet with rain, there is a

danger of electric shock.

• Do not use other methods than specified to install

the speaker. Extreme force is applied to the

speaker and the speaker could fall off, possibly

resulting in personal injuries.

• Use screws that are appropriate for the ceiling's or

wall's material and structure. Failure to do so may

cause the speaker to fall, resulting in material

damage and possible personal injury.

• Ensure that all screws are securely tightened. If

Indicates a potentially hazardous situation which,

if mishandled, could result in death or serious

personal injury.

WARNING

Summary of content (8 pages)

PAGE 1
INSTRUCTION MANUAL COMPACT SPEAKERS BS-1015BSB BS-1015BSW Thank you for purchasing TOA's Compact Speaker. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment. TABLE OF CONTENTS 1. SAFETY PRECAUTIONS ........................... 1 6. INSTALLATION PRECAUTIONS ............... 4 2. GENERAL DESCRIPTION 7. WIRING DIAGRAM ..................................... 4 AND FEATURES ......................................... 2 8. FREQUENCY RESPONSE (1 W, 4 m) ..
PAGE 2
they are loose after installation, the speaker could fall down, possibly resulting in personal injury. • Do not mount the speaker in locations exposed to constant vibration. The speaker or its mounts can be damaged by excessive vibration, potentially causing the speaker to fall, which could result in personal injury. • Do not use anti-rust lubricant. If it contacts resin or rubber parts, they could deteriorate and cause the speaker to fall, possibly resulting in personal injury.
PAGE 3
4. WIRING The terminal cover is not mounted to the speaker unit when shipped from the factory. Note To complete speaker installation, be sure to attach the terminal cover after finishing cable connections. If the unit is left without the terminal cover attached, water or moisture may get inside the speaker, causing the unit malfunction. Step 1. Strip the speaker cable jacket. Step 2. Run the speaker cable through the cable gland. Step 3.
PAGE 4
5. SPEAKER INSTALLATION Step 1. Attach the bracket to the speaker using the supplied screws. Bracket (accessory) Speaker Step 2. Mount the speaker in the desired location using the mounting holes made in the bracket. Note: Bracket mounting hardware is not supplied with the unit. Referring to the bracket's dimensional diagram, prepare the correct type of screws or bolts appropriate to the wall material. Machine screw with washers M5 x 15 (accessory) 6.
PAGE 5
• Speaker • Bracket 50 (1.97") 17-ø9 (ø0.35") 25 (0.98") 123 (4.84") 30 (1.18") 9. DIMENSIONAL DIAGRAM Unit: mm (in) 68 (2.68") 196 (7.72") 262 (10.31") 100 (3.94") 2.3 (0.09") 290 (11.42") ") 1.97 50 ( ") 0.98 25 ( 160º 50 (1.97") 141 (5.55") 186 (7.32") 10.
PAGE 6
PAGE 7
PAGE 8
URL: http://www.toa.
